4 Bins Belt Type HZS90 Concrete Batching Plant Accurate Weighing For Commercial

4 Bins Belt Type HZS90 Concrete Batching Plant Accurate Weighing For Commercial, whose production capacity is 90m3/h, flexibly consists of JS1500 twin shaft concrete mixer, PLB2400 batching machine, cement silos, control system and relevant equipment. On the other hand, the JS1500 twin shaft concrete mixer, compulsory and efficient, can work independently. This kind of 90m3 concrete batch plant is of simple structure, easy installation and disassembling, convenient construction, widely applied to various big and middle industry and civil construction of bridge, highway, water conservancy project and wharf and so on. HZS90 cement batching plant, capable of excellent mixing hard-dry concrete, light aggregate concrete and various mortars, is an ideal equipment to produce commercial concrete.

The concrete batching plant is mainly composed major systems, such as mixing system, batching system, conveying system, powder weighing system, liquid weighing system, dust removing system, Intelligent control system, and other auxiliary facilities.

Main parameters of 4 Bins Belt Type HZS90 Concrete Batching Plant Accurate Weighing For Commercial

Product Introduction of 4 Bins Belt Type HZS90 Concrete Batching Plant Accurate Weighing For Commercial

Mixing system
JS1500 twin shaft compulsory concrete mixer by feeding, mixing, the composition of the discharge, water, electric, cover, chassis, legs and other parts. Mixing system is directly connected by a planetary reducer, open gears, mixing tank, stirring device, oil installations and other components.

Batching system
PLB2400 with 3bins or 4bins batching machine, The optimum vibration lining panel structure with large inclined angular and concentric needle arch design, adjustable pressure reducing plate ensures loading efficiency, stable performance, safe production and convenient use.

Weighting System
In accordance with the national standards of measurement and weighing, sand and gravel from the loader into the concrete batching machine, after measuring, aggregate will be conveyed by belt conveyor(or hopper hoist) into the middle of the mixer located in the middle of warehouse.
Weighing system adopts S-shaped sensor and three-point mounted weighing for fast weigh and high accuracy.

Cement silo system
The cement silo is stored with powder materials, such as cement, fly ash, etc. The powder is communicated with the ash inlet pipe through the bulk cement delivery truck and is directly fed into the powder bin to be stored, finally conveyed to concrete mixer by screw conveyor.

Conveying system
Scientific design, easy to maintain and durable
The belt conveyor allows the friction between the conveyor belt and the transmission wheel to prevent the conveyor belt from slipping while adjusting the effect of the change in conveyor length. belts. An emergency stop switch is used as a safety device while the conveyor belt is in operation. It is located on the head and tail of the belt. It can stop the belt from operating in the event of a failure or accident in the belt drive.

Intelligent control system
Multiple securities, no–downtime, Self-developed production management and control system, plus the patent of fault warning, multiple guarantees to make your equipment never stop; Reports are automatically classified and summarized, and cloud data storage ensures clear data and convenient operation.

Q Can you test our order before shipping?
A Yes. All of our goods will test in factory before shipping to customer.
Q How long it takes to do all the installation
A It's at most 5days processing and manufacturing for single machine,for production line,at most 15days.
Q Can we visit your factory?
A Yes. You can visit our factory at anytime you want.
Q: Can you put our logo on the machine?
Yes,it is available.LOGO and color are usually as per customer's requirement.
Q: What’s the warranty time?
From the date of shipment, 1 year or 1500working hours, whichever comes first.
Q: What’s your payment term?
We accept T/T(30% down payment and balance before shipping) and L/C mostly, but if you prefer other payment terms please contact us for further information.
Q: How long is your delivery time?
Usually, it is 7-10 workdays if the goods are in stock, or it is 15-20 working days if the goods are not in stock, it is according to quantity.

More Photos of 4 Bins Belt Type HZS90 Concrete Batching Plant Accurate Weighing For Commercial
