40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe
40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe
40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe
40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe
40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe
40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe
40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe
40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe
Specifications
Brand Name :
ZHENHENG
Model Number :
Diesel Concrete Pump 40m³
Certification :
SGS, ISO, BV, CE
Place of Origin :
HENAN CHINA
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 sets per month
Delivery Time :
7-15 working days after confirm order
Packaging Details :
Export standard container: 20GP or 40GP, 40HC
Power type :
Diesel
Warranty :
12 Month
Color :
Optional
Type :
Diesel power concrete pump
Capacity :
40m3/h diesel concrete pump
After-sales service provided :
Engineers available to service machinery overseas
Distribution valve :
S tube valve
Conveyor Pipe :
50 &100m
Description

40m3 Diesel Concrete Pump Machine Hydraulic Mobile Concrete Pump

HBT40 has maximum output of 40 cubic meter per hour, equipped with the unique hopper and blade design, so as to less material left and easy to clean. It can adapt to a variety of concrete formulation. Good maintainability, easy to repair and disassemble.

In order to meet the demand of open country and other no power supply constructions, we research and developed the diesel engine concrete pump. Our concrete pump is set of mechanical, electrical and hydraulic technology as one, with reliable performance of smooth operation and strong pumping capability. The diesel engine is with advanced high quality, low emission, low fuel consumption, meet the advanced standard. Reliability and stability is guaranteed by automatic engine regulation.

Product Description of 40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe

Item

HBTS40-10-74R

Max Theoretical Concrete Output(m3/h)

40

Max Theoretical Conveying Distance (vertical Height/Horizontal Distance) (m)

500/150

Max Concrete outlet Pressure(Mpa)

10

Distribution Valve

S Valve

Max Aggregate size(mm)

30

Concrete Slump(mm)

100～200

Concrete Cylinder Diameter(mm)

Φ160×1000

Oil Tank Diameter(mm)

Φ100×φ63×1000

Hopper Capacity/Filling Height (m3/mm)

0.4/1100

Concrete Pumping Pressure (Mpa)

23

Hopper Mixing Pressure (Mpa)

14

Oil Tank Capacity (L)

200

Cleaning Mode

High Pressure Washing

Diesel Motor (kw)

78

Oil Pump (ml/r)

140(Korea KAWASAKI)

Valve Group

Germany Bolseen

Hydraulic Hose

Italy MANULI

Electric

CHNT/Schneider

Dimension(L×W×H)(mm)

5150×1600×2150

Weight (kg)

4300

40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe

Features to 40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe:


1. Reliable performance: adopt Italy hydraulic drive, which reduce reversing impact. S Valves system is easy for maintaining.
2. Complete machine can be taken apart into two, easy to transport and install in mining construction location.
3. Core parts are Japanese Kawasaki original, equipment lifetime and quality is reliable.

40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe

Advantages of 40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe:


1 . Stability:
• Special hydraulic system with double pumps and double circuits: compared with single pump double circuits, the pumping system and distributing system are driven by two independent pumps that allow a more stable oil flow rate to the pumping unit.
• Intelligent control system: advanced technology, easy operation and high reliability electrical system.

2. High efficiency:
• Hopper: High Suction Capacity due to Large Angle Fluent Hopper Design with less feed accumulation area.
• S valve: well designed S valve ensures the smooth flow of concrete.
• Rapid concrete piston substitution: the pistons can be changed easily by a single operator without any special tools in 15minutes. The hydraulic cylinder has an extra stroke to allow the piston to extend from the concrete cylinder.

More Details of 40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe:

40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe

1. Hydraulic system


Double open hydraulic loops with 2 pumps.The reliability of the whole system is also much higher as well as the components' life is prolonged greatly. This is convenient for judgeing and removing trouble.

2. Electric control system


Compared with domestic product, the electric control system is simplest, the element quantity is fewest and its reliability is the highest.

Adopting proximity switch in hydraulic cylinder can realize changing direction with non-touch, which ensures that the direction can be changed reliably.

40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe

40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe

3. Diesel Engine

The pump adopt Weichai diesel engine, a first-class brand in China. It can ensure the power supply of the concrete mixer pump.

4. Cooling system


The radiator equipment makes the working oil temperature of hydraulic system below 70℃ and makes the machine in normal status.

40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe

Q1. Why Choose Us?
A:We have rich experience engineers and professional team to solve different kinds of questions and promise the goods will be shipped as soon as possible when you confirm the order within 15 days

Q2. Computer warranty?
A:12 months after installation.

Q3. What is the material do you use for milling blades and lining board?
A:High chromium alloy wear resistant plate and high manganese alloy lining board.

4. How to be your agent/distributor?
We strive for the mutual long-term win-win cooperative relationships with international companies.We will have assessment on cooperator, and the cooperator must come to visit our factory, sign the cooperative distributor contract and the distributor must finish certain sales volume each year.

40m3 Hydraulic Diesel Concrete Pump Machine Wear Resistant 50 / 100m Conveyor Pipe
