Mobile concrete batching plant with drum mixer, which is self-falling type bipyramid reversed discharging concrete mixing machine.
Aggregate batching and transferring is automatic and precise;
Concrete mixing quality is observable, drum clockwise rotating for mixing, and anti-clockwise rotating for discharging;
The whole plant chassis can be moved easily, don't need to be separated and assembled;
This plant is designed to work without foundation, even cooperate working with horizontal cement silo;
Compared with twin-shaft concrete mixer plant, this concrete batching plant is cheap and save the shipments cost.​

Technical Parameters of YHZM30 Mini Mobile Concrete Bathcing Plant For Easy Transportation

The main features of YHZM30 Mini Mobile Concrete Bathcing Plant For Easy Transportation:
A: The overall layout
Modular design,easy to disassemble.
B:structure characteristics
Unique water supply lines, automatic water supply system, reduced water time and increased production efficiency by 20 %
C:Traction mode
Trailer traction, easy to move and walk.
D: Control System
One-button start mode, simple operation, stable and reliable performance.

a. Tires: Double tires, strong pressure bearing capacity, strong stability, non-slip.
b. Support leg: Quick disassemble and assembly, stabilize machine during work, protect tires, and extend service life.
c. Universal Steering wheel: can be dragged by a medium-sized forklift directly, ensure the direction changing stably.
d. Storage hopper base: moved from the middle to the front generating two advantages:
a). remaining space can be used for the generator, control cabinet, water tank, tool box, etc.;
b). shorten the length of the feeding belt and the feeding time, thereby shortening the single mixing cycle by 10s, and improving the working efficiency.
e. Support steel: Increase the bearing capacity of the chassis and extend the service life.
Compact structure: Movable completely, work on the supporting legs, No foundation needed.

	Concrete Drum 1.Theory Capacity: 30 m³/h 2.Mixing Motor Power: 5.5kw*2 3.Water Pump Power: 1.5kw 4.Discharging Height: 1500mm(Adjustable)
Aggregate Batching Machine 1.Storage Volume: 5.5m³*3 2.Weighing Hopper: 1200L 3.Motor Power: 4kw*3
	Water, Cement and Additive Scales 1. Cement weighing accuracy: ±1% 2. Water weighing accuracy: ±1% 3. Additive weighing accuracy: ±1%

Certifications:

Since ZHENHENG has been established, we have paid the great attention to improvement our quality. In recent years, we have made breakthroughs in market access and qualification certification, provided equipment to consumers with excellent product quality.

Q: Can we visit your factory?
A: Yes. You can visit our factory at anytime you want.
Q: Can you put our logo on the machine?
A: Yes,it is available.LOGO and color are usually as per customer's requirement.
Q: What’s the warranty time?
A: From the date of shipment, 1 year or 1500working hours, whichever comes first.
Q: What’s your payment term?
A: We accept T/T(30% down payment and balance before shipping) and L/C mostly, but if you prefer other payment terms please contact us for further information.
Q: How long is your delivery time?
A: Usually, it is 7-10 workdays if the goods are in stock, or it is 15-20 working days if the goods are not in stock, it is according to quantity.

More photos of YHZM30 Mini Mobile Concrete Bathcing Plant For Easy Transportation
