Electromagnetic Single Phase Electric Motor Vibrator MV Series Small Industrial Variable Speed
Electromagnetic Single Phase Electric Motor Vibrator MV Series Small Industrial Variable Speed
Electromagnetic Single Phase Electric Motor Vibrator MV Series Small Industrial Variable Speed
Electromagnetic Single Phase Electric Motor Vibrator MV Series Small Industrial Variable Speed
Electromagnetic Single Phase Electric Motor Vibrator MV Series Small Industrial Variable Speed
Electromagnetic Single Phase Electric Motor Vibrator MV Series Small Industrial Variable Speed
Electromagnetic Single Phase Electric Motor Vibrator MV Series Small Industrial Variable Speed
Electromagnetic Single Phase Electric Motor Vibrator MV Series Small Industrial Variable Speed
Specifications
Brand Name :
DASION
Model Number :
MV200/3
Certification :
CE&ISO
Place of Origin :
Henan Province, China
MOQ :
25 set
Price :
EXW USD 37.5-126.5 per set
Payment Terms :
T/T, L/C
Supply Ability :
1000 sets per month
Delivery Time :
5-8 working days
Packaging Details :
Wooden cases for electrical motor vibrators
Product name :
MV series small industrial variable speed electromagnetic single phase vibration motor
Force :
2KN
Power :
0.15kw
Weight :
6.8kg
Installation size :
62-74, 106
Color :
Red or your required
Material :
Aluminum shell
Description

MV series small industrial variable speed electromagnetic single phase vibration motor

Vibrating Motors Application

The motor vibrators are widely used in vibratory machinery such as vibrating feeder, vibrating screen, vibrating conveyor, vibrating table, tube feeder, vibrating mineral selection, vibrating drier, crushing machine, vibrating sand machine and doffing machine.metallurgy, coal, mineral processing, building materials, chemical industry, abrasive and other industries of crushing, screening combined equipment.

Vibrating Motors Description

Motor vibrating feeder for crushing production line in the production process, The massive, granular materials from the storage silos in uniform, regular and continuous charging and feeding device. In the gravel production line, can continuous and uniform feeding for crushing machinery. Also could give the roughly sieve for materials. Vibration motor, also known as vibrating motor and vibrator motor, consists of eccentric block to generate exciting force when the motor rotating.

Vibrating Motors Advantages

1.The structure is simple, light weight, low noise, reliable work, high capacity, easy installation and maintenance.
2.Start quickly, stable, stable parking. Easy maintenance.
3.The material groove wear smaller.
4.Can be instantaneous change and open and close the material flow, so the feed volume has a higher accuracy.

5. Exciting force properly match with output power due to advanced design.

6. High vibration efficiency with low noise generation.

7. Adjust exciting force easily only by adjusting angle of eccentric block weight on both side of vibration motor shaft.

8. The direction of exciting force can be changed in line with the installation patterns of the vibrating motor.

9. Can be running under dusty environment except explosion-proof requirement.

10. High quality with competitive price.

11. Different vibration motor combination to meet different product needs.

12. OEM or ODM are accepted.

Vibrating Motors Parameters

No. Model Force(KN) Power(KW) Weight(KG) Installation Size
A B
1 MV40/3 0.3 0.05 4 62-74 106
2 MV60/3 0.7 0.07 4.2 62-74 106
3 MV100/3 1 0.09 4.6 62-74 106
4 MV200/3 2 0.15 6.8 62-74 106
5 MV300/3 3 0.25 9.8 90 125
6 MV400/3 4 0.27 10.3 90 125
7 MV500/3 5 0.5 15.8 105 140
8 MV700/3 7 0.59 16.5 105 140
9 MV800/3 8 0.7 20.6 120 170
10 MV1200/3 10 0.95 21.6 120 170
11 MV1300/3 13 1.3 24.5 120 170
12 MV1600/3 16 1.54 51.6 140 190
13 MV1800/3 18 1.85 52 140 190
14 MV2000/3 20 2.1 51.8 140 190
15 MV2200/3 22 2.4 52.8 140 190
16 MV2300/3 23 2.4 53.6 140 190
17 MV3200/3 32 2.76 96.9 155 255
18 MV4000/3 40 2.9 107 155 255
19 MV5000/3 50 4 112 155 255
52 MV60/3M 0.7 0.08 4.5 62-74 106
53 MV100/3M 1 0.1 5.1 62-74 106
54 MV200/3M 2 0.13 6.8 62-74 106
55 MV50DC-24 0.5 0.1 4.5 62-74 106
56 MV200DC-24 2 0.16 6.5 62-74 106

Electromagnetic Single Phase Electric Motor Vibrator MV Series Small Industrial Variable Speed

Electromagnetic Single Phase Electric Motor Vibrator MV Series Small Industrial Variable SpeedElectromagnetic Single Phase Electric Motor Vibrator MV Series Small Industrial Variable SpeedElectromagnetic Single Phase Electric Motor Vibrator MV Series Small Industrial Variable Speed
