50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
Specifications
Certification :
CE, ISO
Model NO. :
MJ12-1600/2000/2600/2800/3200
Precision :
Precision
Customized :
Customized
Condition :
New
Color :
Customized
Voltage :
220V
Power :
3HP
Saw Wheel Diameter :
470mm
Table Pivot Capacity :
-10o ~45o
Transport Package :
Package
Specification :
CE
Trademark :
G&G
Origin :
China Shandong
HS Code :
84659200
Supply Ability :
100sets/month
Warranty :
1year
Type :
Table Panel Saw
Power Type :
Electric
Layout :
Horizontal
Controlling Mode :
Artificial
Automatic Grade :
Manual
Place of Origin :
China
MOQ :
2 sets
Price :
USD 510-1300
Packaging Details :
Carton/Wooden case
Delivery Time :
30-45days
Payment Terms :
T/T
Description

Adjustable Speed 12" Woodworking Sliding Panel Saw

Company Info.

Basic Info.

Model NO.
MJ12-1600/2000/2600/2800/3200
Precision
Precision
Certification
CE, ISO
Customized
Customized
Condition
New
Color
Customized
Voltage
220V
Power
3HP
Saw Wheel Diameter
470mm
Table Pivot Capacity
-10o ~45o
Transport Package
Package
Specification
CE
Trademark
G&G
Origin
China Shandong
HS Code
84659200
Production Capacity
300/Per Month

Product Description

FOB Price: US $ 1, 100 - 1, 500 / Set
Min. Order Quantity: 5 Set/Sets
Supply Ability: 500 Set/Sets per Month
Port: Qingdao
Payment Terms: T/T

Quick Details
Condition: New
Type: Table Panel Saw
Use: Woodworking
Style: Horizontal
Place of Origin: Shandong, China (Mainland)
Brand Name: GNG
Usage: Woodworking
Voltage: 220V
Power(W): 3HP
Certification: CE/RoHS
Warranty: 1year
After-sales Service Provided: No overseas service provided
Packaging & Delivery
Delivery Detail: 30-45days

Specifications
MODEL MJ12-1600/2000/2600/2800/3200
Description SLIDING SAW MJ12-1600/2000/2600/2800/3200
TECHNICAL SPECIFICATIONS model NO. EXW QINGDAO price
Motor power 3000W
Main table size 385*800mm
Extension table size (cast iron) 440*800mm
Extension table size(stell plate) 440*800mm
Rear extension table size 310*500mm
Sliding panel size 1600*270mm
Extension sliding panel size 680*580mm
Cross cut fence 1200-2200mm
Main blade size 315*30*3mm
Small blade size 90*20*3mm
Main blade speed 4000rpm
Small blade speed 5800rpm
Max cut depth 100mm @90° 80mm @45°
Max distance-blade to rip fence 1220mm
Sliding panel strock 1600/2000/2600/2800/3200mm
Packing size(mm) 940x765x1000 940x785x1000 1600x766x1040 1600x766x1040 1600x766x1040 1660x250x320 2060x250x320 2660x250x320 2660x250x320 3260x250x320
N.W/G.W 210/240KGS 210/240KGS 240/300KGS 240/300KGS 240/300KGS 40/50KGS 45/55KGS 56/68KGS 58/70KGS 60/72KGS

50HZ Cnc Sliding Table Saw Adjustable Speed Cnc Panel Saw Machine
Features
1,Circular rod structure with chromium plating, compared with the past linear ball sliding table, has high positioning accuracy, long service life and promotes smoothness.
2,Upgrade large motor, the machine uses pure copper motor, the default main motor is 4kw, the scoring motor is 0.75kw. If you need to cut solid wood and other plates, you can customize 5.5kw+1.1kw large motor.
3,The ruler to adopt the European style large ruler, stable and non-displacement, effectively ensure the precision in the cutting process of the board.
4,Main and scoring saw blade first by a scoring saw blade to open a line, followed by a main saw blade can be easily cut with high precision to prevent chipping burrs.
5,The machine saw blade adopts an electric lifting system, which is more accurate than a hand-cranked saw blade.

Application
It is used for cross-cutting of various kinds of wood-based panels, such as veneers, particleboards, fiberboards, plywood and solid wood panels, aluminum alloys, plexiglass panels, etc.

This is our company's main product. This product has been selling well in Europe, North America, Australia and South America for more than ten years. We can adjust the details according to the different needs of our customers.
