CE 3.6m3/H 5.5KW 4Mpa 60L/Min Cement Grouting Pump
CE 3.6m3/H 5.5KW 4Mpa 60L/Min Cement Grouting Pump
Specifications
Brand Name :
KEMING
Model Number :
ZBS
Certification :
CE, MA
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
100 Sets/Per Month
Delivery Time :
5~8 Work Days
Packaging Details :
Export Wooden Packing
Theory :
piston pump
Capacity :
60L/min
Pressure :
4Mpa
Motor :
5.5KW
Description

Better Flexibility Best Choice ZBS Cement Grouting Pump For Sale

Grouting Pump Application:

1. ZBS cement grout pump can be used to grout cement paste, mortar and other liquid (particle size ≤ 3mm).Medium temperature is between 5 to 80 ℃.The water cement ratio (weight ratio) of solid-liquid mixture should be 0.75 or higher. The maximum output pressure should be 4 MPa, and work flow 3.6 m3/h.

2. ZBS cement grout pump is widely used pressure grout in tunnels, coal mine, bridges and dams, building foundation, and other underground projects.

3. ZBS cement grout pump can work in inflammable and explosive sites,dusty and rainy environment or other bad conditions.

Grouting Pump Features:

1. ZBS3.6/4-5.5 cement grout pump is a single cylinder double action piston pump.

2. ZBS grout pump is mainly composed of pump head, pump body, frame, protective cover, clutch, water filter, air chamber and pressure gauge. The pump body, pump head, frame and other parts are bolted to facilitate the decomposition of difficult transportation and removal.

Technical Parameters:

Model
ZBS grouting pump
Rated output
3.6 m3/h
Rated pressure
4 Mpa
Reciprocating times
85/min
Motor power
5.5KW
Volumetric coefficient
≥92%
Pump efficiency
≥84%
Piston diameter
75mm
Piston stroke
85mm
Sipper diameter
20mm
Weight
280kg
Dimension
1500×500×700mm
