126 Wires Through Hole Electrical Slip Ring Multi Circuits Contact Custom slip ring for any mechnical equipment
126 Wires Through Hole Electrical Slip Ring Multi Circuits Contact Custom slip ring for any mechnical equipment
126 Wires Through Hole Electrical Slip Ring Multi Circuits Contact Custom slip ring for any mechnical equipment
126 Wires Through Hole Electrical Slip Ring Multi Circuits Contact Custom slip ring for any mechnical equipment
126 Wires Through Hole Electrical Slip Ring Multi Circuits Contact Custom slip ring for any mechnical equipment
126 Wires Through Hole Electrical Slip Ring Multi Circuits Contact Custom slip ring for any mechnical equipment
Specifications
Brand Name :
Haurem
Model Number :
HRT150
Certification :
CE RoHS
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1000pieces/month
Delivery Time :
2 weeks ARO
Packaging Details :
Standard/On Request
Advatage :
High product precision
Channel :
1~126
Contact Resistance :
≤10mΩ ( 50rpm )
Electrical Noise :
Max 30mΩ
Operating Humidity :
60%RH or higher
Rotating Speed :
200RPM
Series :
Through hole slip ring
Temperature :
-40℃~+80℃
Voltage Rating :
400VAC/VDC
High light :
Anti-interference design and no noise in transimission
Description

HRT150 series slip ring apply advanced fiber brush technology with high performance precious meteal, all of this keep our slip ring high lubricity,low friction, low contact wear and low noise. Besides, each brush bundle is made up of many brush wire with multi contact points in each circuit guaratee this kind of slip ring's better performance.

Electrical Spec. 　 Options
Rating voltage 380VAC Flange for set up
Rating current 5A /Ring,10A /Ring The wire exit direction,length is optional
Insulation resistance 1000MΩ@500VDC Can combine more circuits:1-126Ring
Dielectric strength 600VDC@50HZ Higher voltage and current capacity
Electrical noise 10mΩ@6VDC,50mA,5Rpm The wire exit direction,length is optional
Mechanical Spec Environment
Speed3 200Rpm Working temperature -40℃~+80℃
Torque 60N.cm Mechanical vibration MIL-SID-810E
Protection class IP54--IP68 Humidity 10% to 90% RH
Contact material Precious Metal Materials Lead Free,RoHS compliant
Lead Wire 12 color Teflon CE Certified YES
Life 50 million revolutions The life of slip ring is up to revolutions, operation environment and temperature etc.

Model Through Bore Circuits Rated Current Rated Voltage Outer diameter Rated Speed
HRT015 series 15mm 1-6 2A/Ring or signal Power:600VAC/VDC, Singal:240VAC 42mm 600Rpm
HRT012 series 12.7mm 1-36 5A,10A/Ring or signal Power:600VAC/VDC, Singal:240VAC 56mm 600Rpm
HRT025 series 25.4mm 1-72 5A,10A,15A/Ring or signal Power:600VAC/VDC, Singal:240VAC 86mm 300Rpm
HRT038 series 38.1mm 1-72 5A,10A,15A/Ring or signal Power:600VAC/VDC, Singal:240VAC 99mm 300Rpm
HRT050 series 50mm 1-72 5A,10A,15A/Ring or signal Power:600VAC/VDC, Singal:240VAC 120mm 300Rpm
HRT060 series 60mm 1-126 5A,10A,15A/Ring or signal Power:600VAC/VDC, Singal:240VAC 135mm 300Rpm
HRT080 series 80mm 1-126 5A,10A,15A/Ring or signal Power:600VAC/VDC, Singal:240VAC 160mm 200Rpm
HRT100 series 100mm 1-126 5A,10A,15A/Ring or signal Power:600VAC/VDC, Singal:240VAC 185mm 200Rpm
HRT150 series 150mm 1-126 5A,10A,15A/Ring or signal Power:600VAC/VDC, Singal:240VAC 260mm 200Rpm

126 Wires Through Hole Electrical Slip Ring Multi Circuits Contact Custom slip ring for any mechnical equipment

As a precious slip ring manufacturer for more than 10 years,Hunan Haurem Technology Co. Ltd. (HRM) owns a skilled management team and excellent design team already developed more than then thousands slip ring solutions, this keeps our technology advanced always around the world.

According to your special application requirements, our technical team will customize the slip ring with economically,high quality and reliability for you, please contact us at anytime @ WHATSAPP:13302489809
