High Voltage Outdoor Ceramic Dropout Fuse 35kv OEM Available
High Voltage Outdoor Ceramic Dropout Fuse 35kv OEM Available
High Voltage Outdoor Ceramic Dropout Fuse 35kv OEM Available
High Voltage Outdoor Ceramic Dropout Fuse 35kv OEM Available
High Voltage Outdoor Ceramic Dropout Fuse 35kv OEM Available
High Voltage Outdoor Ceramic Dropout Fuse 35kv OEM Available
Specifications
Brand Name :
Suntech
Model Number :
SCO35
Certification :
ISO
Place of Origin :
China
MOQ :
1 Set
Price :
Get the newest price
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
90000PCS Per Month
Delivery Time :
7 days after deposit
Packaging Details :
Box with Pattets For Shipping
Product Name :
35kv cutout switch fuse
Safety Standards: :
IEC
OEM :
Available
Rated Voltage :
33KV
Material :
Composite Polymer
Rated Current :
100A
Description

High Voltage Outdoor Ceramic Dropout Fuse 35kv Cutout Switch Fuse

The drop fuse is composed of two parts:

An insulating bracket and a fuse tube. The static contact is installed at two ends of the insulating bracket, the movable contact is installed at both ends of the fuse tube, and the fuse tube is composed of an inner arc extinguishing tube and an outer layer.

It consists of a phenolic paper tube or an epoxy glass tube. The load drop fuse enhances the elastic auxiliary contact and the arc extinguishing cover to divide and combine the load current.

1. Small size,Light weight,resistance to impact,no collision damage during transportation,flexible installation,suitable for use in the switch cabin.

2. Special structure,the overall compression molding,no air gap,good sealing performance,moisture-proof and explosion-proof 3. Large creepage distance,good hydrophobicity,strong stain resistance,stable performance and reduce operation maintenance. 4. Unique formula of zinc oxide varistor, small leakage current,slow aging,long service life.

5. With DC reference voltage,rectangular flow capacity and high current and large current withstand capacity are higher than standard requirement.

porcelain drop out fuse product parameters
Type Rated voltage
(KV)		 Rated current
(A)		 Breaking current
(A)

Lightning Impulse

voltage(BIL)
(KV)

Power frequency

wihstand voltage
(KV)

Creepage

distance
(mm)

 Weight
(kg)		 Dimensions
(cm)
ST3-24/100 24-27 100 10000 150 65 540 11 51×38×16
ST3-24/200 24-27 200 12000 150 65 540 11.5 51×38×16
ST3-24/100F 24-27 100 10000 150 65 540 11.5 51×38×16
ST3-24/200F 24-27 200 12000 150 65 540 12 51×38×16
ST4-33/100 33-36 100 10000 170 72 680 12 60×41×14
ST4-33/200 33-36 200 12000 170 72 680 12.5 60×41×14
ST4-33/100F 33-36 100 10000 170 72 680 12 60×41×14
ST4-33/200F 33-36 200 12000 170 72 680 12.5 60×41×14
