Self Supporting ASTM A36 ASTM A572 GR65 GR50 Mobile Antenna Tower
Self Supporting ASTM A36 ASTM A572 GR65 GR50 Mobile Antenna Tower
Self Supporting ASTM A36 ASTM A572 GR65 GR50 Mobile Antenna Tower
Self Supporting ASTM A36 ASTM A572 GR65 GR50 Mobile Antenna Tower
Specifications
Brand Name :
Suntech
Model Number :
Telecommunication Tower
Certification :
ISO
Place of Origin :
China
MOQ :
1 Tower
Price :
Get the newest prices
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000 Metric Ton/Metric Tons Per Year
Delivery Time :
35 days after deposit
Packaging Details :
Exported Containers
Product Name :
Self Supporting Tower
Material :
ASTM A36,ASTM A572 GR65, GR50, Etc.
Usage :
Electricity Distribution
Application :
Mobile Telecom Tower
Surface Treatment :
Hot Dip Galvanised
Lifetime :
At least 30 years
Description

Custom Transmission Lattice Tower Self Supporting Steel Mobile Antenna Tower

Quick Detail:

Self supporting tower usually is 3-leg or 4-leg tower, and its material is steel pipe or angle steel. As for the connection,

tubular tower is connected by flange, and angle steel tower is connected by nuts and bolts.

Manufactory supplied self supporting 3 legged telecom steel tube tower are made of steel tube, designed on

a tubular base pattern.The communication tower is optimized for medium to heavy loads which is used for

standard cellular sites. 3 Legs Tubular High Quality 60m Telecommunication Steel Tower can be equipped

with a variety of accessories, such as work or rest platforms, antenna mounts, safety devices,obstruction lights,

lightning protection kit and more. All of the accessories can be installed at any desired height and orientation

according to customer Specification.

Height From 10M-100M or according to client’s requirement
Suit for Electric Power Transmission and Distribution
Shape Polygonal or Conical
Material Normally Q235B/A36,Yeild Strength≥235MPa
Q345B/A572,Yeild Strength≥345MPa
As well as Hot Rolled coil from ASTM572, GR65,GR50,SS400
Power Capacity 10kV to 500kV
Tolerance of the dimension According to client’s requirement
Surface treatment Hot-dip-galvanized following ASTM123, or any other standard by client’s requirement
Joint of Poles Slip joint, flanged connected
Standard ISO9001:2008
Length of per section Within 13M once forming
Welding Standard AWS(American Welding Society)D 1.1
Production Process Raw material test-cutting-bending-welding-dimension verify-flange welding-hole drilling-sample assemble-surface clean-galvanization or power coating /painting-recalibration-packages
Packages Packing with plastic paper or according to client’s requirement
Life Period More than 30 years

Detials of Telecommunication Antennas galvanized steel structure

Self Supporting ASTM A36 ASTM A572 GR65 GR50 Mobile Antenna Tower

Foundation bolts of steel monopole tower Entry hole of steel monopole tower Ladders of steel monopole tower

Application:

Self Supporting ASTM A36 ASTM A572 GR65 GR50 Mobile Antenna Tower
