76m Self Supporting GSM Telecommunication Steel Lattice Tower
76m Self Supporting GSM Telecommunication Steel Lattice Tower
76m Self Supporting GSM Telecommunication Steel Lattice Tower
76m Self Supporting GSM Telecommunication Steel Lattice Tower
Specifications
Brand Name :
Suntech
Model Number :
Telecom Tower
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 Tower
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
30000 Metric Ton/Metric Tons Per Year
Delivery Time :
40-45days after deposit
Packaging Details :
Exported Containers
Material Grade :
Normally Q345B/A572，Q235B/A36
Item Number :
Telecommunication Tower
Application :
GSM Telecommunication
Height :
5-100m
Wind Pressure :
0.35-1 KN/m2
Connection :
Flanges, Inserting, Connection Plate and Bolts
Description

Customized 76m Self Supporting Tower Telecommunication Steel Lattice Tower

Monopole tower

Single tube tower also called monopole tower, is a commonly used type, with beautiful appearance,

covering an small area of 9 to 18 square meter, cost - effective , and is adopted by majority of the

construction. Tower body adopt more reasonable section, which is connected through high strength

bolt. It has the characteristics of easy installation and can adapt to a variety of complicated field site.

Guyed Tower

Guyed tower has a novel appearance,and its biggest characteristic is strengthened by using steel guy wire.

Guyed tower is a common type of communication tower which is economical and practical. It is lighter and

cheaper than the others. It is very suitable for the geographical wide areas.

Self Supporting Tower

Self supporting tower usually is 3leg of 4leg tower, and its material is steel pipe or angle steel. As for the

connection, tubular tower is connected by flange, and angle steel tower is connected by nuts and bolts.

Lattice steel tower Telecom steel angle tower
Height 10---100m
Shape Round face/Polygonal face
Appearance Hot-dip-galvanized steel poles
Wind speed As the customer request
Wind pressure As the customer request
Material Q345B/A572, minimum yield strength >=345MPA
Connection structure Overlap/Flange connection
Quality system GB/T19001-2008-ISO9001,GB/T 24001-2004-ISO 14001,GB/T28001-2001
Standrd China/British/America standard/European standard
Color As the customer request
Spare parts Parts for connection or installation will be provided
Lifetime 50 years
Platform Quantity 1-5pcs
Antenna Support 6-30pcs
Microwave Dish 6-30pcs

Quick Detail:

1. Angle steel tower is also named as lattice tower, electrical tower;

2. Angle steel tower is widely used as electrical power transmission and distribution;

3. Angle steel tower is the frame structure for all kinds of power lines, especially for above 100KV high

voltage electrical powers;

Hot-dip galvanized bolts and nuts
All the iron towers produced by our company have matching hot-dip galvanized bolts and nuts.

All the screws in the height of 9 meters from the ground for the poles and towers and the connecting steel bolts.

The cross arm are all anti-theft bolts to solve the problem of theft prevention of the poles and towers.

76m Self Supporting GSM Telecommunication Steel Lattice Tower
