Specifications
Brand Name :
Tongveo
Model Number :
TEVO-NV10U
Certification :
ISO9001,CE,FCC,ROHS
Place of Origin :
China
MOQ :
1 piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability :
3000 piece per month
Delivery Time :
1-10 working days
Packaging Details :
Foam packaging inside; standard carton packaging outside
video output :
USB2.0
Sensor :
1/3 inch HD Color CMOS
Pixel :
2.1 mega pixel(16:9)
Zoom :
HD1080P 10X optical zoom
Features :
Pan: ±175°(max speed 80°/S), Tilt: 35°~55°(max speed 60°/S)
Color :
Black
Horizontal angle :
51.3 degree
Control temernal :
RS-232, RS-485, IR remote control
Resolution :
1080P (1920 *1080）
Warranty :
2 years
Description

OEM auto focus 10x zoom video conference camera for PTZ broadcasting

The TEVO-NV10U Pan/Tilt/Zoom (PTZ) camera has USB video output.
It is equipped with a 1 /3 inch HD Color CMOS with 2.1 mega pixel (16:9) and Full HD 1080p output resolution & a high dynamic image of 30 fps.
The superior 10x optical zoom lens, excellent white balance, and exposure mode delivers a clear image even in low light or the extreme contrast of brightness and darkness in a conference room.

The camera covers a wide shooting angle and achieves high-speed, quiet, and precise positioning with smooth PTZ operations.
There are up to 256 preset setting movements and stable remote controlling for displaying effective and efficient presentations.
The TEVO-NVl OU is applicable for video conferencing in a medium conference room.

NV10U Parameters
Image Sensor 1/3 inch HD Color CMOS
Effective pixel 2.1 mega pixel(16:9)
Horizontal Resolution 1080P30/25, 720P30/25
Signal standard NTSC/PAL
Zoom 10x optical zoom
Minimum luminance 0.5Lux at F2.0
Focal length f=5.0mm~50.0mm F1.8(W)~2.1(T)
Horizontal Angle Near-end 51.3°~Far-end 4.46°
Gain control Auto
Focus Auto
White balance Auto
SNR ratio ≥50dB
Shutter speed 8 to 1/10000s (auto)
Preset position IR remote control supports 9 presets,
　 PELCO Protocol supports 256 presets
Pan/Tilt movement range Pan: 175°(max speed 80°/S), Tilt: 35°~55°(max speed 60°/S)
Control terminal USB, RS-232, RS485
Control Protocol VISCA, PELCO-D, PELCO-P (RS-232, RS485)
Video output USB
Video Compression Format YUV, MJPG, H.264
Noise Reduction 2D/3D
Work temperature -10°C-~50°C
Storage temperature -20°C~60°C
Baud rate 38400/9600bps
Decoder Built-in
Address set 1~256

OEM Autofocus H264 USB PTZ Conference Camera 10x Zoom For Broadcasting


Features:

10x optical zoom
Sleek and intelligent design
Plug & Play USB Connectivity
Crystal clear HDI080P image quality
Accurate, smooth and silent PTZ Movement
Preset: 9 via IR remote setting (255 via RS232)
Superior quality with Full Glass Lens Material
51.3.wide field of view with no video distortion
Video Compression Format supports YUV, MJPG, H.264
1 /3 inch high quality, 2.1 MEGA PIXEL (16:9) CMOS sensor
2D and 3D NR for best video quality in different lighting conditions
Support ceiling mount, wall mount and tripod mount (Reverse mountable)
Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control Utilizing belt drive technology the PTZ is ultra-quiet and fast, while being very smooth
Compalible with all popular applications and cloud systems:
