Custom Stamping Die Parts , Stamping Machine Parts Grinding / CNC Machining
Custom Stamping Die Parts , Stamping Machine Parts Grinding / CNC Machining
Specifications
Price :
Negotiable
Place of Origin :
Dongguan, China(Mainland)
Certification :
ISO9001: 2015
Packaging Details :
Protect the part with film, Put box in plastic bag with label
Delivery Time :
4.It only takes 7-8 working days once the order is placed. Priority arrangement for urgent orders
Supply Ability :
1200-1500 units per month
MOQ :
Negotiable
Payment Terms :
T/T 50% as deposit 50% before shipment or negotiation
Brand Name :
Guan Yao
Product Name :
Stamping Die Parts
Molding Type :
Herizontal and Vertical type
Machining Processing :
EDM, Grinding, CNC, Wire Cutting And So On
OEM ODM Service :
Available
EDM And Surface Grinding Precision :
0.002mm
Hardness :
58HRC
Description

Custom Stamping Die Parts Machining Processing: EDM, Grinding, CNC, Wire Cutting

Special Features

Business Service OEM accepted
Processing Equipment CNC milling machines, wire cutting machines,
surface grinding machines, EDM machines, and more.
Application Auto mold
Measuring& testing Height Gauge, Hardness tester, dimensional detector, projector,
micrometer and so on.
Machining Basis Primary cusromer's drawings, 2D or 3D is ok
Surface Treatment according to our customers’ requirements
Tolerance Accuracy of grinding: 0.001 mm;
Accuracy of EDM: 0.002 mm;
Accuracy of Wire-cutting: 0.002mm;
Accuracy of CNC: 0.002mm
In short, the requirment of tolerance as customer's demand.
OEM ODM Service Yes
Quality Assurance 1. Incoming material control to make sure all the raw materials are qualified.
2. Operators follow the daily check list to check the machines to make sure they are in good conditions, and follow the spec to make products.
3. Use qualified operators and correct parameters to make sure good quality.
4. According to the quality assurance procedure to check the quality.
5. Full quality check after product before shipping.


Introduction of Stamping Die Parts

Name: Custom Made Precision Machining Mold Parts

Equipment List: Horizontal injection machine, Double injection machine, Vertical injection machine, stamping machine.

Injection Molding Machines: We have 43 machines, buyed from Japan Fanuc, Taiwan YiZhan and China HongRui.

4. Processing methods/ technologies: For the automobile mold parts, it is processed by precision grinders and electrical discharge machines.

5. Processing equipments: Milling , Grinding, Wire cutting, EDM, etc.

6. Application: It's assembled on a car mold as a components.

7. Surface treatment: For this mold part, its surface treatment is polishing. And other surface treatments can be available in our factory, such as: PCD caoting, DLC caoting and mirror polishing, etc.

8. Design software: UG, PRO/E ,CATIA, SOLIDWORK, CAD, PDF, etc.


Machined Processing
Grinding Mirror EDM
1. EDM Processing
Finish(Ra): 0.13
Accuracy: 0.002-0.005mm
Min Clear radius: 0.03mm
2. Grinding Machine Processing
Finish(Ra): 0.05
Accuracy: 0.001mm
Wire Cutting and CNC
1. Wire-cutting Processing
Finish(Ra): 0.08
Accuracy: 0.002mm
Min Clear radius: 0.05mm
2. High Speed CNC Processing
Finish(Ra): 0.1-0.15
Accuracy: 0.002mm
RPS: 35000
Milling Assembly
1. Professional tool makers for prefect assembly.
2. Milling Processing For pre-rough machining.
Stamping Insert Molding
We have 2 automatic stamping machines with 45 tons to produce terminals for insert molding parts. We can provide one-step service for our customers.

Metal stamping is a manufacturing process used to convert flat metal sheets into specific shapes. It is a complex process that can include a number of metal forming techniques — blanking, punching, bending and piercing, to name a few.

Our Advantage

High quality /durability

Low Cost

Fast turnaround time

Packing Procedure

1st Step: Wash the part.

2nd Step: Dry the part with cold air gun.

3rd Step: Protect the part with film (also with Anticorrosive oil for specific material in need) in plastic box with foam on both 2 sides.

4th Step: Put box in plastic bag with label together with drawing, measurement report, etc.
