Specifications
Brand Name :
KETONG
Model Number :
SCP100
Certification :
CE
Place of Origin :
CHINA
MOQ :
1SET
Price :
10000-50000USD/SET
Supply Ability :
100SETS /MONTH
Packaging Details :
Bulk
Description

We always thought this is cooperation , not only purchase and manufacture , so only win-win ,it can continue longer . We are here to ensure the best service all the time .

Scan climber design Mast working platform Single and Twin mast

Motor brand :NORD , no need safety device if use this motor , Save cost and more safe.

1.Product description Of Best Quality Of SCP100 mast climbing work platform:

SCP type construction platform/mast climber works with the same driving principle with the building hoist. Its main parts can be interchanged with building hoist such as mast sections,rack, pinion, reducing device and so on.

And its width and length can be changed according to request. It is requisite equipment in construction job. Additionally ,it is no need for foundation so that it is easy to change the working site.

Safety Features:

1. With overload

2. With balance device

3. Moving synchronize device(used in twin mast platform)

4. With anti-falling safety device( can install as client need)

5. With constant speed safety device, prevent platform sliding down overspeed

6. With hand-operation landing equipment, it can be landed by man when supply power cut off.

2.Technical data Of Best Quality Of SCP100 mast climbing work platform:

PLATFORM TYPE

TWIN MAST MC-36/15e ASCLIMBER

SINGLE MAST MC-36/15e ASCLIMBER

Maximum height

150m

150m

Maximum distance from ground to first anchoring

7m

7m

Maximum total capacity

1000kgs

1000kgs

Maximum distance between anchors

9m

9m

Maximum length of working area

23m

23m

Width of working area

1.5m

1.5m

Maximum extension towards wall

50cm

50cm

Motor power

4x2,2 KW

2x2,2 KW

Elevation speed

8.3/min

9.2/min

Geared motor electrical consumption

2x5,4A

5,4A

Consumption upon elevation start

2x24,3A

24,3A

Power supply

380-415V-50Hz

380-415V-50Hz

Maximum allowed wind speed in service – w/o anchors

28.4 mi/h

28.4 mi/h

Maximum allowed wind speed in service

34.6 mi/h

34.6 Km/h

Maximum force against rails

198.5 lb

198.5 lb

Maximum wind speed during mounting/dismounting

28.4 mi/h

28.4 mi/h

Maximum wind speed when out of service

102.6 mi/h

102.6 mi/h

Leq Acoustic level

60 dB(A)

60 dB(A)

3.Advantage of TDT/JIUY Suspended Platform:

- Economic, low price and good quality

- High Efficiency, it can replace hanging scaffolding for most high rise building work.save labor and time.

- Experienced, the first factory who manufacture pedal suspended platform in china. we have more than ten years experience in

this field.

- Safety, in past ten years.we never have big accident.

- Brand wire rope.

- Patented products

4.Quality Control

Every product have to pass five QC stages before leaving the plant, your comfort is our best effort.

KETONG wish you have a nice cooperation with us .
