Eco Friendly 3 Ton Heavy Duty Forklift Solid State Lcd Digital Meter Wide View
Eco Friendly 3 Ton Heavy Duty Forklift Solid State Lcd Digital Meter Wide View
Eco Friendly 3 Ton Heavy Duty Forklift Solid State Lcd Digital Meter Wide View
Eco Friendly 3 Ton Heavy Duty Forklift Solid State Lcd Digital Meter Wide View
Eco Friendly 3 Ton Heavy Duty Forklift Solid State Lcd Digital Meter Wide View
Eco Friendly 3 Ton Heavy Duty Forklift Solid State Lcd Digital Meter Wide View
Eco Friendly 3 Ton Heavy Duty Forklift Solid State Lcd Digital Meter Wide View
Eco Friendly 3 Ton Heavy Duty Forklift Solid State Lcd Digital Meter Wide View
Specifications
Brand Name :
Z-L forklift
Model Number :
Z-L930
Certification :
CE ISO
Place of Origin :
China
MOQ :
1
Supply Ability :
100sets /month
Delivery Time :
10-15
Packaging Details :
1070x125x45
Rated Load :
3000KG
Load Center :
500
Lifting Height :
4500
Minimum Right Angle Channel Width :
2950
Minimum Turning Radius :
2950
Rated Power :
38kw
Cylinder Amount :
4
Fuel Tank Volume :
70L
Working Pressure :
19mpa
Type :
Powered Pallet Truck
After-sales Servi :
e Provided: Engineers available to service ma
Total weight :
4707
Fork Length: :
1070mm
Condition :
new
Description

2 Tons Fork Lift Trucks Small Warehouse Electric Forklift Truck Sell At a Low Price New Condition

Compact And Flexible Structure
Convenient Driving With Comfortable Seat
Safe Braking Is Reasonable And Reliable
It Is Suitable For Domestic Airports Transportation And Material Handling.
No Pollution And No Noise

All the products purchased from BSTenjoy one year or 2000 hours (which occurs first) warranty. During the warranty period, if there is any part broken because of quality problem (except easy-damaged parts), the defective parts will be repaired or replaced free of charges.

Generals Model Unit ZL-930
Power type Diesel
Rated capacity Kg 3000
Load center mm 500
Dimensions Lift height mm 4500
Free lift height mm 142
Fork size (L× W× T) mm 1070× 125× 45
Mast inclination F/R Deg 6° /12°
Front overhang mm 497
Overall Dimensions Length to face of fork mm 2680
Overall width mm 1225
Mast lowered height mm 2095
Overhead guard height mm 2120
Turning radius mm 2460
Min. right angle aisle width mm 2105
Performance Travel speed Unload I/II Km/h 9/20
Full load I/II Km/h 8.8/19.5
Lift speed mm/s 400
Max. grade ability % 20
Max. drawbar pull Kn 13.5
Self weight Kg 4900
Wheels & Tires Tires Front 28x9-15-12PR
Rear 6.50-10-10PR
Tread Front Q mm 1000
Rear S mm 970
Wheelbase mm 1700
Min. ground clearance
(unload/full load)		 Mast mm 152/110
Frame mm 166/160
Drive units & Control Battery V/Ah 12/105
Engine Model XINCHAI C490BPG
Rated output Kw/rpm 37/2650
Rated torque N. m/rpm 148/1800
Displacement cc 2540
Transmission Type Hydraulic
Shift Fwd/Rwd 1/1 Power shift
Operating pressure Mpa 17.5

Packaging

1)Normal Packing for free

Inner Pack: Bubble Film + PP Knitted Band
Outer Pack: Wrapping Film + Iron Pallet

2)Plywood case packing for option

weifang best power equipment Co.Ltd ndustrial is committed to offer not only products with high quality and performance and competitive price, but also in-time delivery and comprehensive after-services.
