60 Meter / Minute Rack And Pinion Lift For Building Construction
60 Meter / Minute Rack And Pinion Lift For Building Construction
Specifications
MOQ :
1 set
Price :
Negotiate
Payment Terms :
T/T, L/C
Supply Ability :
150 sets per month
Delivery Time :
30 days
Packaging Details :
Suitable for Export
Model Number :
hoist for building construction
name :
Hoist For Building Construction
Application :
Vertical transportation of man and materials in construction site or building site, bridges, chimney, plants, etc..
Feature :
High Safety
Production :
Processed by CNC machines, Laser, Robots in assembly line
Material :
Q345B Steel
Finishing :
Sandblasting and Painted, Galvanised
Description

High Safety 60 Meter/Minute Hoist For Building Construction

Production advantage:

1. Adopting advanced technology both at home and abroad,SC series construction elevator is novel in design,resonable in structure,simple in operation,covenient in assembly and disassembly,safe and reliable in working.

2. The unit incorporates famous brand electric components and main parts in transmission mechanism.The steel structure is made of high-quality steel material and welded with CO2 gas shield welding.Surface paint is made with imported raw materials in brmiant ,long lasting colors.

3. The unit is provided with reliable safety interlock devices,safety switch,breakage protection switch,upper and lower limits and limit switches ,etc,Progressive dropping safety devices and safety protection hook are provided.

4. The safety design and configuration fully comply to national standards.

Details

The modular and standardizing system makes the Kangbo construction elevators be flexible, efficient, safe, productive, low energy consumptive and ownership cost, making them the best choice for both construction and rental companies.

Production and Materials
KANGBO implements the true modular design of rack and pinion hoists, standardization and fine finishing of lifts parts and spare parts, and assembly line production. The material elevator components are versatile and universal.
The construction material elevator structural parts are made of 16Mn and Q345 high strength steel.

Parameters

Item & Article No. SC200BG, KP-B11; SC200/200BG, KP-B12
Payload Capacity 2,000KG per Cage
Lifting speed 0–60 meter/minute.
Max. lifting height 450 m
Cage width (internal) 1.5 m
Cage length (internal) 3.2 m
Cage height (internal) 2.35 m
Motor control FC control
Engine power 3x15 KW per Cage
Gearbox Helical reducer
Safety device type centrifugal brake
Power supply range 380–500 V, 50 or 60 Hz, 3 phase
Type of mast square column 650*650 mm with bolted rack
Length mast section 1.508 m
Rack module 8
