Men And Cargo Transportation 2000KG Building Site Hoist
Men And Cargo Transportation 2000KG Building Site Hoist
Specifications
Brand Name :
KANGBO
Model Number :
Building site hoist SC200BG KP-B11 SC200/200BG KP-B12
Certification :
TUV
Place of Origin :
CHINA
MOQ :
1 set
Price :
In US Dollar
Payment Terms :
T/T, L/C
Supply Ability :
150 sets per month
Delivery Time :
30 Days
Packaging Details :
Export package
Name :
Building Site Hoist
Application :
Men And Cargo Transportation
Design :
Modular and According to European Standard
Production :
Processed by CNC machines, Laser, Robots in assembly line.
Finishing :
Sandblasting and Painted, Galvanised
Load :
2,000KG
Description

Men And Cargo Transportation 2,000KG Building Site Hoist

Building Site Hoist Introduction

The building hoist can be widely used in industrial and civilian construction, bridge, under well, big chimney as well as shipping industry to carry people and materials. As permanent or semi-permanent equipment, elevator can be used in different sites such as warehouse, high tower, etc.

With the advantages of reliable performance, safety, easy carrying, high adaptability, it can reduce operators' work intensity.

With many advanced technology integrity, strict control on each making process, high ratio of price and quality, building hoist has become a symbol of lifter with high quality and excellent after-sales service.

Building Site Hoist Production and Materials


KANGBO implements the true modular design of rack and pinion hoists, standardization and fine finishing of lifts parts and spare parts, and assembly line production. The material elevator components are versatile and universal.
Main structure frame are made of 16Mn and Q345 high strength cold roll steel plate, cut by laser, process by CNC machines in tool fixtures, welded by robots.

Optional equipment
An intelligent elevator control system, with functions of fault detect, display and alarm, and automatic cage landing/stop and floor selector, is available.
Automatic greasing machine for rack and pinion elevator is availble.

Building Site Hoist Parameters

Item & Article No. SC200BG, KP-B11; SC200/200BG, KP-B12
Payload Capacity 2,000KG per Cage
Lifting Speed 0–60 meter/minute.
Max. Lifting Height 450 m
Cage Size (internal) 3.2(Length)*1.5((Width)*2.35(Height) meter
Motor Power 3x15 KW per Cage
Motor Control Frequency Control (FC)
Invertor Power (KW) 1*55KW per Cage
Gearbox PIELI Helical Gearbox
Anti-drop Safety Device Centrifugal Brake
Power Supply Range 380–500 V, 50 or 60 Hz, 3 Phase
Mast Section Square Column 650*650*1508 mm with Bolted Rack
Rack module 8
