8300x2560x3450mm Dump Truck Tipper , Industrial Dump Truck With One Bed Cabin
8300x2560x3450mm Dump Truck Tipper , Industrial Dump Truck With One Bed Cabin
8300x2560x3450mm Dump Truck Tipper , Industrial Dump Truck With One Bed Cabin
8300x2560x3450mm Dump Truck Tipper , Industrial Dump Truck With One Bed Cabin
8300x2560x3450mm Dump Truck Tipper , Industrial Dump Truck With One Bed Cabin
8300x2560x3450mm Dump Truck Tipper , Industrial Dump Truck With One Bed Cabin
8300x2560x3450mm Dump Truck Tipper , Industrial Dump Truck With One Bed Cabin
8300x2560x3450mm Dump Truck Tipper , Industrial Dump Truck With One Bed Cabin
Specifications
Brand Name :
SINOTRUCK HOWO
Model Number :
ZZ3257N3647A
Certification :
SGS, BV, CTN
Place of Origin :
CHINA
MOQ :
1 Unit
Price :
Price is negotiable
Payment Terms :
L/C, T/T
Supply Ability :
2000 Unit / Per Month
Delivery Time :
30-35 days
Packaging Details :
Nude
Engine capacity :
9.726L
Dimensions (l x w x h) (mm) :
8350*2600*3450mm
Max Speed :
75km/h
Transmission type :
Manual
Capacity (load) :
21 - 30t
Emission standard :
Euro 2
Product name :
Dumper Truck
Engine :
WD615.47
Cab :
HW76,with Air conditioner
Description

2020 Year SINOTRUK HOWO Heavy Duty Dump Tipper Truck With 371HP Engine

1. HOWO 6x4 Dump Truck Main Details.

-. Engine from 371HP to 420HP.

-. With one bed cabin and A/C. right hand drive cabin could optional

-. 16-20m3 big cargo box, middle lifting or front lifting.

-. Other name: HOWO tipper truck, howo dumper truck, howo tipping truck.

Dimensions (unloaded) 8300x2560x3450mm
Cargo body size(mm) 5800x2300x1500, T-middle lift, bottom 8mm, side 6mm
Approaching angle/departure angle (°) 19/27
Overhang (front/rear) (mm) 1500/1560
Wheel base (mm) 3600+1350
Max speed (kph) 75
Curb weight (kg) 12380
Loading weight (kg) 12490
Engine Model WD615.47, water-cooled, four strokes,
6 cylinders in line with water cooling, turbocharged and interfolding, directly injection
Fuel type Diesel
Horse power, max (kW/rpm) 371HP,273/2200
Emission Euro 2
Fuel tanker capacity 300
Transmission Model HW19710
Brake system Service brake Dual circuit compressed air brake
Parking brake spring energy, compressed air operating on rear wheels
Steering system Model ZF8118
Front axle HF9 Drum, Steering with double T-cross section beam
Rear axle HC16, Pressed axle housing, central double reduction with differential locks between axles and wheels
Tyre 12.00R20, radial tire
Electrical system Battery 2X12V/165Ah
Alternator 28V-1500kW
Starter 7.5kW/24V

8300x2560x3450mm Dump Truck Tipper , Industrial Dump Truck With One Bed Cabin

8300x2560x3450mm Dump Truck Tipper , Industrial Dump Truck With One Bed Cabin

8300x2560x3450mm Dump Truck Tipper , Industrial Dump Truck With One Bed Cabin

-2. HOWO 6x4 Dump Truck Video.

-3. FAQ.

-. Terms of paymemt.

30% as the deposit by T/T, 70% balance before delivery.

-. What’s your MOQ?

One unit trailer or truck. But suggest two trailers one time to save the freight.

-. Whats your delivery time.

20-25 working days after received the deposit.

-. What is your terms of shipment?
The trailer could arrange shipment by ro-ro ship, bulk cargo vessel, container etc.

-. Can you accept the custom made?

Definitely! We could design the trailer according to your request.

-. What’s your warranty?

All of our trailers meet the CIQ, SGS, BV, ADR, FORM E quality certificate, and we will supply one year warranty for the trailers.

8300x2560x3450mm Dump Truck Tipper , Industrial Dump Truck With One Bed Cabin
