Nylon PA6 PA12 Red Recoil Hose , 12mm Outer Dia Polyamide Tube For Pneumatic Brake System
Nylon PA6 PA12 Red Recoil Hose , 12mm Outer Dia Polyamide Tube For Pneumatic Brake System
Specifications
Place of Origin :
Ningbo China(Mainland)
Brand Name :
FLUIDAC or OEM
Certification :
ISO9001
Model Number :
PACL8x6-6M-R
MOQ :
5 piece
Price :
USD5--
Packaging Details :
Boxes, Cartons,Wooden cases,Pallets
Delivery Time :
Within 20 days after receiving payment or deposit
Payment Terms :
TT Advance/30% deposit,70% by copy Bill oflading,Western Union,Paypal
Supply Ability :
80000 Meters Per month
Feature :
Non-toxic,tastless
Working pressure :
1.5~2MPa
Working temperature :
-40~80℃
Outer Dia. Metric size :
6mm, 8mm, 10mm,12mm
Applications :
Grease&Lubrication lines,Instrumentation,Refrigeration
Colours :
Red
Material :
Polyamide PA6 PA12
Product material :
Recoil Hose
Description

Nylon PA6 PA12 Red Recoil Hose , 12mm Outer Dia Polyamide Tube For Pneumatic Brake System

Good flexibility Polyamide Nylon PA6 PA12 material Recoil tube O.D size 6mm,8mm,10mm,12mm working temperature -40~80℃,working pressure 15~20Bar e.g PACL 8x6-6M-R

Quick Detail:

* PACL Series Polyamide PA6 PA12 material Recoil hose

* working temperature:-40~80℃

* working pressure 1.5~2MPa

* tuter Dia. Metric 6mm, 8mm, 10mm,12mm

* conform to ROHS environment protection requirement

* good flexibility for piping working

* pressure-resistance,wear-resistance

* resistance toSolvents,alkalizes.oils,greases,potroleum,fungus,molds

* resistance to dilute mineral and organic acids.

* heat and light stabilized

* wide applicable range of tempeature

* various tube colours for option make it easier to distinguish pipes one another

* non-toxic,tastless

Tag: Polyamide Tube,PA recoil hose,Nylon windpipe

Applications:

PACL Seres Nylon Recoil tube used widely in air conditioning,air lines,Chemicals, compressed air, coolant,dispensing equipment, Fuel&Oil, Grease&Lubrication lines,Hydraulics, Instrumentation, laboratory,paint supply,Refrigeration etc

PACL Recoil hose use as windpipe,oil pipe for Agriculture and industrial filed.It also used in vehicles brake system.

Specifications:

ORDERING CODE

PACL

8x6

6M

BU

Type

O.Dx I.D Metric Size

Length Meters

Colours

PACL:Polyamide Nylon Tube

6x4

6M:6Meters

T: TRANSPARENT

8x6

9M:9Meters

10x7.5

BU:BLUE

PACLW:Polyamide Nylon tube with connector

12x9

12M:12Meters

B:BLACK

12.7x9.6

15M:15Meters

R:RED

SPECIFICATION

1,Material: Polyamide

2,Working Fluids:Air,water,oil

3,Working Pressure:1.5~2MPa

4,Working Temperature:-40~80℃

MODEL NO

O.D

I.D

COIL O.D

COIL I.D

BURSTING PRESSURE(Bar)

WORKING PRESSURE(Bar)

PACL6x4

6

4

52

40

60

20

PACL8x6

8

6

66

50

60

20

PACL10x7.5

10

7.5

80

60

45

15

PACL12x9

12

9

110

84

45

15

PACL12.7x9.6

12.7

9.6

110

84

45

15

Nylon PA6 PA12 Red Recoil Hose , 12mm Outer Dia Polyamide Tube For Pneumatic Brake System
