-76cmHG - 1500Psi Pneumatic Air Pressure Gauge , Pressure Manometer 40mm-150mm Dial Size
-76cmHG - 1500Psi Pneumatic Air Pressure Gauge , Pressure Manometer 40mm-150mm Dial Size
Specifications
Place of Origin :
Ningbo China(Mainland)
Brand Name :
FLUIDAC or OEM
Certification :
ISO9001
Model Number :
PG20U-4P-100X
MOQ :
50piece
Price :
USD1.0--
Packaging Details :
Boxes, Cartons,Wooden cases,Pallets
Delivery Time :
Within 20 days after receiving payment or deposit
Payment Terms :
TT Advance/30% deposit,70% by copy Bill oflading,Western Union,Paypal
Supply Ability :
50000 Pieces Per month
Dial size :
40mm~150mm
Pressure range :
-76cmHG~1500PSI
Thread size :
1/8”~3/8”with tip or without tip
Type :
Liquid filled type,vacuum type,efrigeration type
Product name :
Vacuum Pressure Gauge Dial
Material :
Stainless steel or steel
Description

-76cmHG - 1500Psi Pneumatic Air Pressure Gauge,Pressure Manometer 40mm-150mm Dial Size

PG series Pressure Gauge dial size 40mm~150mm,thread size 1/8”~3/8”BSP,BSPT, NPT.Pressure range -76cmHG~1500PSI e.g PG20U-4P-100X with Liquid Vacuum and Refrigeration type.Case material stainless steel or steel

Quick Detail:

* PG series pressure gauge

* Case material stainless steel or steel

* movement material brass

* dial size 40mm~150mm

* pressure range -76cmHG~1500PSI

* flexible connection model for option

* thread size 1/8”~3/8” with tip or without tip for option

* liquid filled type,vacuum type,refrigeration type etc

* high accuracy,fast response

* steady and reliable

Applications:

PG series pressure gauge application covering all the industrial area and scientific research field,it is used widely in the heating pipe network,oil and gas transporation,water and gas supplying,vehicle maintenance,especially use in the industrial control system pressure measurement.

Specifications:

ORDERING CODE

-76cmHG - 1500Psi Pneumatic Air Pressure Gauge , Pressure Manometer 40mm-150mm Dial Size

-76cmHG - 1500Psi Pneumatic Air Pressure Gauge , Pressure Manometer 40mm-150mm Dial Size

Vacuum Pressure Gauge

◇Dial size: 40mm,50mm,63mm,76mm,88mm,100mm,113mm,150mm

◇Case and bezel: Black steel

◇Window :Glass or plastic

◇Connection:Brass,back or bottom

◇Thread:1/8" ,1/4",1/2",3/8" (BSP,BSPT,NPT)

◇Range: -76cmHG-0/-30inHG-0

◇Movement: Brass

-76cmHG - 1500Psi Pneumatic Air Pressure Gauge , Pressure Manometer 40mm-150mm Dial Size

Liquid Filled Pressure Gauge

◇Dial size: 40mm,50mm,63mm,76mm,88mm,100mm,113mm,150mm

◇Case and ring: Stainless steel case, roll ring

◇Window :Polycarbonate

◇Connection:Brass,back or bottom

◇Thread:1/8" ,1/4",1/2",3/8" (BSP,BSPT,NPT)

◇Range:-30inHG-0-30-100------1500PSI

◇Movement: Brass

-76cmHG - 1500Psi Pneumatic Air Pressure Gauge , Pressure Manometer 40mm-150mm Dial Size

Panel Pressure Gauge

◇Dial size: 40mm,50mm,63mm,76mm,88mm,100mm,113mm,150mm

◇Case : Black steel

◇Window :Glass or plastic

◇Connection:Brass and back with front flange

◇Thread:1/8" ,1/4",1/2",3/8" (BSP,BSPT,NPT)

◇Range:-30inHG-0-30-100------1500PSI

◇Movement: Brass

-76cmHG - 1500Psi Pneumatic Air Pressure Gauge , Pressure Manometer 40mm-150mm Dial Size

Normal Pressure Gauge with back or bottom connection

◇Dial size: 40mm,50mm,63mm,76mm,88mm,100mm,113mm,150mm

◇Case and bezel: Black steel

◇Window :Glass or plastic

◇Connection:Brass,Back or bottom

◇Thread:1/8" ,1/4",1/2",3/8" (BSP,BSPT,NPT)

◇Range:-30inHG-0-30-100------1500PSI

◇Movement: Brass

Pressure Gauge,pressure manometer
