Pellet Stoves Draft Inducer Blower Motor 78W 0.97A Exhaust Fan High Temperature
Pellet Stoves Draft Inducer Blower Motor 78W 0.97A Exhaust Fan High Temperature
Pellet Stoves Draft Inducer Blower Motor 78W 0.97A Exhaust Fan High Temperature
Pellet Stoves Draft Inducer Blower Motor 78W 0.97A Exhaust Fan High Temperature
Pellet Stoves Draft Inducer Blower Motor 78W 0.97A Exhaust Fan High Temperature
Pellet Stoves Draft Inducer Blower Motor 78W 0.97A Exhaust Fan High Temperature
Pellet Stoves Draft Inducer Blower Motor 78W 0.97A Exhaust Fan High Temperature
Pellet Stoves Draft Inducer Blower Motor 78W 0.97A Exhaust Fan High Temperature
Specifications
Brand Name :
MH motors
Model Number :
MH84-84558
Certification :
UL
Place of Origin :
China
MOQ :
320pcs
Price :
Negotiable ( EXW)
Payment Terms :
T/T
Supply Ability :
1500PCS/day
Delivery Time :
30 work days
Packaging Details :
Standard exporting carton package, ship by sea or airfreight
Product Name :
Pellet Stoves 78W 0.97A Draft Inducer Blower Exhaust fan in High Temperature
Model Type： :
MH84-84558
Rated Voltage/Frequency :
115Vac/60Hz
Current（A) :
0.97
Input Power（W） :
78
Speed（RPM) :
2540
Hi-Pot TEST :
1500vac50hz,1Ma,1s
Insulation Class :
B
Bearing Type :
NMB Ball Bearing
Protect Method :
TP
Appliction :
PELLET STOVE
Air Volume（CFM) :
102
Wind Speed(m/s) :
13.6
Agency :
UL
Start Voltage :
71V 60HZ
High Light :
Pellet Stoves ,78W 0.97A, Draft Inducer Blower, Exhaust fan ,High Temperature
Description

Pellet Stoves 78W 0.97A Draft Inducer Blower Exhaust fan in High Temperature

The exhaust fan in this pellet stove is designed to operate at high temperatures. This feature ensures that the fan can withstand the heat generated during the combustion process without getting damaged. It helps to control the flow of combustion gases and ensures efficient and effective exhaust of the flue gases.

Quick Detail:

Product Name: Pellet Stoves 78W 0.97A Draft Inducer Blower Exhaust fan in High Temperature Model Type:: MH84-84558
Rated Voltage/Frequency: 115Vac/60Hz Current(A): 0.97
Input Power(W): 78 Speed(RPM): 2540
Hi-Pot TEST: 1500vac50hz,1Ma,1s Insulation Class: B
Bearing Type: NMB Ball Bearing Protect Method: TP
Start Voltage 71V 60HZ Air Volume(CFM): 102

Wind Speed(m/s):

 13.6 Agency: UL

For detail information, please contact us for catalogue, thanks!

Typically used in high temperature draft inducer applications.

Pellet Stoves Draft Inducer Blower Motor 78W 0.97A Exhaust Fan High Temperature

Product Feature:

1. Powered by 3.3’’ shaded pole motor.

2. Quiet,vibration-free design.

3. Can handle up to 500°F in housing.

4. Higher performance available with 3.3’’ diameter motor.

5. Four-piece sheet metal blower.

6. Ball bearing designed, lasting long running

Air Flow Curve:

Pellet Stoves Draft Inducer Blower Motor 78W 0.97A Exhaust Fan High Temperature

Welcome your business chat and visit.

Shanghai MH Electric Co.,Ltd has several years of experience engineering and manufacturing drafr inducer exhaust fan motors and blowers.Our Team members have more than 18 years of rich experience in the motor field. MH can provide the most cost-effective C-frame motor and air moving solutions for customers.

FAQ

Q1- What is the warranty of the motors?

The warranty is 18 months from the shipping date.

Q2- Can you design and make the motor as required?

Yes, we provide both ODM and OEM products.

Q3- What is your advantage?

Besides the good quality and the competitive price, we offer the short lead time and quick response.

Q4- What is your terms of payment?
T/T 30% as deposit, and 70% before delivery. The term can be negotiated for long-term business.

Q5- How to get the accurate quotation?

The accurate price will be quoted after the specification and mounting dimension of the motor are checked.

Q6- Do you test all products before the delivery?
Yes, all products are tested OK before the delivery

Q7- Do you have any MOQ for motors?

Usually our MOQ is one pallet. But we accept the small quantity for the trial order.

Q8- Do you have other products?

Yes, besides the shade pole motors and blowers ,we also offer OEM production for some industrial motors such as single phase AC motor, 3 phase industrial motor, stainless steel motor, BLDC fan motor etc... And we offer the sourcing service for other products required.

Thank you very much for viewing this page
Sincerely looking forward to our cooperation!
