Double Inlet Centrifugal Blower Fan High Air Pressure And Airflow Low Noise
Double Inlet Centrifugal Blower Fan High Air Pressure And Airflow Low Noise
Double Inlet Centrifugal Blower Fan High Air Pressure And Airflow Low Noise
Double Inlet Centrifugal Blower Fan High Air Pressure And Airflow Low Noise
Double Inlet Centrifugal Blower Fan High Air Pressure And Airflow Low Noise
Double Inlet Centrifugal Blower Fan High Air Pressure And Airflow Low Noise
Specifications
Brand Name :
CPMDJ
Model Number :
CPZ7-5
Certification :
CCC
Place of Origin :
Made in China
MOQ :
100PCS
Price :
Negotiable
Payment Terms :
TT, LC
Supply Ability :
10000000
Delivery Time :
15-35 days
Packaging Details :
Foam+Carton
Product name :
High air pressure and airflow low noise double inlet centrifugal blower fan
Power :
200W
Protect Feature :
Totally Enclosed
Winding :
Copper Wire
Housing :
Aluminum
Speed :
820RPM
CFW :
2000
Warranty :
1 year
Description

High air pressure and airflow low noise double inlet centrifugal blower fan

Specification:

Fan model Motor model Voltage Frequency Speed Air volume Current Capacitor
CPZ7-7 YDK90-6 203V-240V 50/60Hz 850RPM 1000m³/h 0.9A 5μF
YDK200-4 203V-240V 50/60Hz 1150RPM 1500m³/h 1.8A 10μF
CPZ8-8 YDK200-6 203V-240V 50/60Hz 820RPM 2000m³/h 2.0A 10μF
YDK300-4 203V-240V 50/60Hz 1200RPM 2200m³/h 2.1A 10μF
CPZ9-9 YDK250-6 203V-240V 50/60Hz 850RPM 2000m³/h 1.9A 10μF
YDK375-6 203V-240V 50/60Hz 850RPM 2000m³/h 3.5A 10μF
YDK375-4 203V-240V 50/60Hz 1200RPM 2500m³/h 3.5A 10μF
YDK550-4 203V-240V 50/60Hz 1150RPM 3250m³/h 4.6A 20μF
CPZ10-10 YDK450-6 203V-240V 50/60Hz 850RPM 3000m³/h 3.5A 20μF
YDK550-4 203V-240V 50/60Hz 1150RPM 3250m³/h 4.6A 20μF
CPZ12-9 YDK750-6 203V-240V 50/60Hz 830RPM 3000m³/h 7.2A 30μF
YDK900-4 203V-240V 50/60Hz 1250RPM 6000m³/h 8.0A 30μF
CPZ12-12 YDK750-6 203V-240V 50/60Hz 830RPM 3000m³/h 7.2A 30μF
YDK900-6 203V-240V 50/60Hz 880RPM 7000m³/h 8.6A 30μF

Double Inlet Centrifugal Blower Fan High Air Pressure And Airflow Low Noise

Mould
Phase
 Power Voltage Frequency Speed(Rpm)
Pole
CPZ7-5
1 phase
200W
220V
50hz
820
2
type
Current
 Bearing Protection class Ratation: Insulation class:
Certification
rang hood motor
2.0A
Ball
IP44
clockwise
B
CCC

Centrifugal fan is a new kind of variable speed, high efficincy, and low noise Type centrifugal fan, the fan, compact structure, easy installation, small volume, windhigh pressure, large amount of small vibration, with single phase voltage regulator or inverter, can carry out Strict control speed.especially suitable for noise, big air volume range of ventilated place.

Double Inlet Centrifugal Blower Fan High Air Pressure And Airflow Low Noise

Product tags

blower ventilator fans

,

high pressure blower fan

,

cfm blower fan
