High Speed Air Conditioner Indoor Fan Motor For Antiviral 25W/35W / HVAC AC Motor For Air Cooler
High Speed Air Conditioner Indoor Fan Motor For Antiviral 25W/35W / HVAC AC Motor For Air Cooler
High Speed Air Conditioner Indoor Fan Motor For Antiviral 25W/35W / HVAC AC Motor For Air Cooler
High Speed Air Conditioner Indoor Fan Motor For Antiviral 25W/35W / HVAC AC Motor For Air Cooler
High Speed Air Conditioner Indoor Fan Motor For Antiviral 25W/35W / HVAC AC Motor For Air Cooler
High Speed Air Conditioner Indoor Fan Motor For Antiviral 25W/35W / HVAC AC Motor For Air Cooler
High Speed Air Conditioner Indoor Fan Motor For Antiviral 25W/35W / HVAC AC Motor For Air Cooler
High Speed Air Conditioner Indoor Fan Motor For Antiviral 25W/35W / HVAC AC Motor For Air Cooler
Specifications
Brand Name :
CPMDJ
Model Number :
YDK95-25-6
Certification :
CCC
Place of Origin :
Made in China
MOQ :
100PCS
Price :
Negotiable
Payment Terms :
TT, LC
Supply Ability :
10000000
Delivery Time :
15-35 days
Packaging Details :
Foam+Carton
Product Name :
Air Conditioner Indoor Fan Motor
Winding :
100% Cooper Wire
Frequency :
50/60HZ
Voltage :
110v/220v
Model No. :
YDK95-25-6
Function :
Ac Motor Specification
Application :
UV Air Disinfection
Description

High Speed Air Conditioner Indoor Fan Motor For Antiviral 25W/35W / HVAC AC Motor For Air Cooler

Product features of AC HVAC Indoor Fan Motor

1, Reversible plug for easy rotation
2, Quick installation
3, Automatic overload
4, Thermal protection
5, High efficiency, High reliability, Little vibration, Low noise

Technical Parametersof AC HVAC Indoor Fan Motor

Rated Voltage 110/115/127/140V/208V/220/230V/380V/440V
Output Power 120W
Speed R. P. M 500-2600r/min
Frequency 50/60HZ
Protection Class IP21
Insulation Class BF
Type Asynchronous air conditioner fan motor
Efficiency IE1, IE2, IE3, IE4
Input Power 10-1500W
Insulation Class E, B, F
Phase Single-phase
current 0.2A-2A
Poles 2/4/6/8/10
air conditioner fan motor Air Conditioning
Use Fan Motor for Air Conditioner, air cooler, cleaner,Fan Coil Unit and Other HVAC Systems
Certification CCC, CE, RoHS, UL, VDE
More Models of AC HVAC Indoor Fan Motor
Model Voltage(v) Frequency(Hz) Output(w) Speed(rpm) Capacitor(μF) Insulation(Class)
YDK83-20-4 220/110 50/60 20 1300 2 B
YDK93-16-4 220/110 50/60 16 1300 1.5 B
YDK93-25-4 220/110 50/60 25 1300 2.5 B
YDK120-30-8 220/110 50/60 30 520 3 B
YDK120-50-8 220/110 50/60 50 520 4 B
YDK139-100-22 220/110 50/60 100 480 6 B
YDK95-25-6 220/110 50/60 25 880 2.5 B
YDK95-35-6 220/110 50/60 35 880 3 B
YDK95-45-6 220/110 50/60 45 880 3.5 B
YDK120-60-6 220/110 50/60 60 850 4 B
YDK139-150-6 220/110 50/60 150 900 10 B
YDK139-250-6 220/110 50/60 250 900 10 B

High Speed Air Conditioner Indoor Fan Motor For Antiviral 25W/35W / HVAC AC Motor For Air Cooler

Our Service of AC HVAC Indoor Fan Motor

● Online service: we can talk on Trade manger , Email, Phone, Wechat and so on.
● Customer service: we accept OEM,with your own design, brand and label.
● Sample service:we will send samples for free, if you decide to buy our product
● Presale service: We will try our best to answer you every question in time.

● In-sale service: We will produce the goods with high quality; and pack carefully. We will also keep contact with you when the goods are ready for delivery until it reached safely.

● After-sale service:If you have any question, please contact us at any time

About us

Changzhou Changpeng Motor Co., Ltd., established in 2009, covered an area of 5,440 square meters, is a professional motor manufacturer, designing and producing all kinds of motors for room, commercial and central air conditioners. It specializes in the researching, designing, developing, and manufacturing of AC motors and DC motors. The main products are environmentally friendly air conditioning motor, cooling fan motor, indoor and outdoor air conditioner motor, water air conditioner motor, fan coil motor, induction fan motor, axial fan motor, heat-pump water heater motor, moveable air cooler motor, brushless DC motor, air purification equipment motor, centrifugal fan motor, external rotor fan motor and other customized motors based on customer’s requirements.
Application of AC HVAC Indoor Fan Motor
Suitable to Antiviral for UV Air Disinfection
Notes of AC HVAC Indoor Fan Motor
The above mentioned specification is representative specification,The specification can also be designed and manufactured
according to customers requirement.
The products of 100-120V,200-240V,60Hz can also be supplied as requested.
We will not give special notice on changes,please contact our technical department for further information.

Packing and Delivery of AC HVAC Indoor Fan Motor

1. Trade Terms: FOB, CIF, CNF, EXW, DOOR TO DOOR.
2. Payment Terms: T/T, L/C, Western Union.
3. Payment Condition: 30% deposit in advance, 70% balance before delivery.
4. Delivery Time: 15-30 days after deposit (if T/T).
5. Shipping: By sea, by air and by express delivery
