Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor
Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor
Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor
Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor
Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor
Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor
Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor
Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor
Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor
Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor
Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor
Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor
Specifications
Brand Name :
CPMDJ
Model Number :
YSK140-120-6
Certification :
CCC
Place of Origin :
Made in China
MOQ :
100PCS
Price :
Negotiable
Payment Terms :
TT, LC
Supply Ability :
10000000
Delivery Time :
15-35 days
Packaging Details :
Foam+Carton
Type :
Asynchronous Motor
Phase :
Single-phase
Protect Feature :
Totally Enclosed
Efficiency :
IE 1
Product Name :
Air Conditioner Condenser Fan Motor
Protection class :
IP21
Winding :
Copper Wire
Capacitor :
4uF
Rotation :
CW-LE
Insulation :
B
Bearing :
Ball/Sliding Bearing
Port :
SHANGHAI PORT
Description
Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor

Condenser fan motors are installed in air conditioner condensing units to power the fan blades that cool the refrigerant in the unit's condensing coil. These electric motors are commonly used to replace worn-out or damaged condenser fan motors with the same specifications to prolong the life of the air-conditioning equipment.

Permanent Split Capacitor Condenser Fan Motors feature higher starting torque and energy efficient performance with cooler operating temperatures. Multiple-horsepower designs replace motors within the HP range listed below, and simplify installation with a single wiring setup, ensuring you have the right motor on-hand for same-day service.

Technical Parameters
MODEL (VOLTAGE) Frequency Output Power Rated speed ROT Capacitor(μF) Replaces
OEM model
YDK140-120-6A 208-230 50/60 1/6HP 1075/2 SPD REVERSIBLE 5/370 PM310668
YDK140-120-6A5 208-230 50/60 1/6HP 1075RPM REVERSIBLE 5/370 5KCP39DGS375S
YDK140-120-6A6 208-230 50/60 1/6HP 1075RPM REVERSIBLE 5/370 FSE1016SV1
YDK140-120-6A7 115 50/60 1/6HP 1075/3 SPD REVERSIBLE 5/370 5KCP39DGP729S
YDK140-120-6A8 115 50/60 1/6HP 1075/3 SPD REVERSIBLE 5/370 A.O.SMITH 9647
YDK140-150-6A 208-230 50/60 1/5HP 1075/2 SPD REVERSIBLE 5/370 PM310543
YDK140-150-6A2 220-240 50/60 1/5HP 900RPM CW-SE 5/370 PM310544
YDK140-185-4A13 220/240 50/60 1/4HP 1050RPM REVERSIBLE 10/370 PM3104161
YDK140-185-4A15 208-230 50/60 1/4HP 1625RPM REVERSIBLE 5/370 FASCO D783
YDK140-185-4A16 115 50/60 1/4HP 1625RPM REVERSIBLE 5/370 FASCO D782
YDK140-185-6A10 208-230 50/60 1/4HP 1075RPM REVERSIBLE 5/370 5KCP39FGM599T
YDK140-185-6A11 208-230 50/60 1/4HP 1075RPM REVERSIBLE 5/370 PM3104160

Product Feature

· Designed to meet manufacturer’s requirements for drive ventilation units
· Capacitor Included And Mounted On PSC Models
· Automatic Reset Thermal Overload Protector
· Continuous Duty,Air Over
· Ball Bearings Unless Noted

Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor

Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor

About us

Changzhou Changpeng Motor Co., Ltd. is an ac motor manufacture. We not only can produce high quality goods, but also have good relationship with all our customers.

For us, we not only business partner, as a matter of fact,we are family. Therefore, welcome all of you back home! We are expecting you!

Air Conditioner Condenser Fan Motor, HVAC Ventilation System AC Motor

1.We are professional manufacture with more than 60 years experience in motors.
2.Every year 500,000 to 600,000pcs of electric motor were exported to others countries.
3.We test the material before production and three to four times when producing to ensure the goods in good quality, also we produce motors according to your quirement.
4.Best production capability,best quality control,best service
5.We can be your OEM manufacturer with your authorization of brand.

Our Service

● Online service: we can talk on Trade manger , Email, Phone, Wechat and so on.
● Customer service: we accept OEM,with your own design, brand and label.
● Sample service:we will send samples for free, if you decide to buy our product
● Presale service: We will try our best to answer you every question in time.

● In-sale service: We will produce the goods with high quality; and pack carefully. We will also keep contact with you when the goods are ready for delivery until it reached safely.

● After-sale service:If you have any question, please contact us at any time

Packing and Delivery

All our goods will be delivered 1 month after receiving your payment. The goods will be packed in a container, which one container including 5000pcs.We will inform you before we send out the product.
