Specifications
Brand Name :
Coolmay
Model Number :
QM3G series
Certification :
CE
Place of Origin :
China
MOQ :
1 unit
Price :
US$92~598 /pcs
Payment Terms :
T/T, Paypal, Western Union, Credit Card
Supply Ability :
60,000 pcs per month
Delivery Time :
1-3 days for samples
Packaging Details :
Carton box
Product name :
HMI PLC Controller
DI/DO :
Max 30DI/30DO
AI/AO :
Max 16AI/8AO
Input :
DC24V
Output :
Relay, transistor
OEM/ODM :
Yes
Protocol :
Modbus RTU, TCP, Ethernet IP
Software :
Free to offer
Control :
Motors, valves, switches, sensors...
Applications :
Packaging, irrigation, boiler, cooler...
Description

Coolmay PLC Controller Module HMI Screen PLC Programming All-in-one Programmable Logic Controller Automation

Coolmay PLC Controller Module HMI Screen PLC Programming All-in-one Programmable Logic Controller Automation

Product Descriptions

Coolmay HMI PLC QM3G series integrated logic control, analog input and output, and HMI functions. There are multiple sizes touch screen including 4.3”, 5”, 7”, 10”. The PLC can be configured up to 30DI/30DO, 16AI/8AO. It supports 6 high speed count inputs and 8 high speed pulse output.

Model

 QM3G-43FH QM3G-50FH QM3G-70FH QM3G-70KFH QM3G-100FH
Dimension 134*102*34mm 151*96*36mm 200*146*36mm 226*163*35.6mm 275*194*36mm
Type 4.3"TFT 5"TFT 7.0"TFT 7.0"TFT 10.1"TFT
Resolution 480*272 800*480 800*480 800*480 1024*600
I/O level
  • Input: Passive NPN, public terminal isolated
  • Transistor output: Low level NPN, COM connect to negative
  • Relay output: Normally open dry contact
DO type
  • MT: 2A/point, 4A/4 point COM, 5A/12 point COM
  • MR: 2A/point, 5A/12 point COM
High speed count input Single phase 6 channel 60KHz, or 2 AB 60KHz + 1 AB 10KHz, or 2 ABZ 60KHz + 1 AB phase 10KHz

High speed pulse output (available for transistor output)

8 channels, Y0-Y3 is 100KHz, Y4-Y7 is 10KHz.

High-speed counting + high-speed pulse < 480KHz
PLC COM port 1x RS232, 1x RS485
Software

Coolmay TPWorks HMI software

PLC is compatible with GX Works2

Coolmay PLC Controller Module HMI Screen PLC Programming All-in-one Programmable Logic Controller Automation

Coolmay PLC Controller Module HMI Screen PLC Programming All-in-one Programmable Logic Controller Automation

Company Introduction

Coolmay is a manufacturer in automation industry for 17 years, covering an area of 3,000 square meters with more than 50 engineers. The products include integrated HMI/PLC, HMI, PLC, integrated servo/PLC, VFD, which have been exported to over 100 countries, including agencies in India, Argentina, Brazil, Russia, UK, Spain and other countries to provide local technical supports. Over the years we achieved 96% customer satisfaction and over 80% repurchase rate. We have a warehouse in Spain, better realized faster delivery with less shipping cost.
