5 Inch Industrial Human Machine Interface HMI Support Modbus Protocol RS485 RS232
5 Inch Industrial Human Machine Interface HMI Support Modbus Protocol RS485 RS232
5 Inch Industrial Human Machine Interface HMI Support Modbus Protocol RS485 RS232
5 Inch Industrial Human Machine Interface HMI Support Modbus Protocol RS485 RS232
Specifications
Brand Name :
Coolmay
Model Number :
MT6050H
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGra
Supply Ability :
100,000 Sets per month
Delivery Time :
3-8 working day
Packaging Details :
Packed with standard carton box
Dimension :
146*88*25mm
Ethernet port :
optional
Display :
5 inch
Description

5 inch Industrial Human Machine Interface HMI Support Modbus Protocol RS485 RS232

Human-Machine Interface (HMI) connects industrial control equipment such as programmable logic controllers (PLC), frequency converters, DC speed regulators, and meters. It is a digital device that uses the display screen to write working parameters or input operating commands through an input unit (such as a touchpad, a mouse, etc.) to realize information

Specs Dimension 146*88*25mm
Cutout size 135*72mm
Display size 108*65mm
Weight(kg) Appox. 0.33 kg
Display Display 5” TFT

Resolution

(pixels)

 800*480
Brightness 300cd/m2
Contrast ratio 400:1
Backlight LED
Backlight time 60,000 h
Display color 65536 true colors
Touch type 4-wire resistive panel
Storage ROM 128MB
RAM 64MB
CPU ARM9 core 400MHz
Operating system WINCE 5.0
Interface USB port USB 2.0×1 (USB port and can be connected to external USB flash drive, mouse, etc.)
Download port Yes (Mini type B male port cable for program download
Ethernet port Optional
COM port 1 RS232 and 1 RS485
Protocol Support MODBUS, free port and common PLC communication Protocol
Other Audio Optional
Calendar Yes
Input Voltage Default as DC12~24±10%V
Consumption 150mA*24V
Protection Class IP65 (front panel)
Temperature Ambient environment: 0～50℃ | Storage environment: -20～70℃
Humidity 20%～90% RH
Certification CE
Software CoolMay HMI programming software

Product Features:

  • Provides a large number of vector libraries and supports self-built gallery.
  • High-precision,high-reliability resistive touch panel.
  • Supports various formats of static images and GIF animations.
  • Support all fonts WINDOws provided.
  • 60,000 TFT true color display.
  • Hseries support vertical display.

5 Inch Industrial Human Machine Interface HMI Support Modbus Protocol RS485 RS232

Packaging:

The products will be under testing for 1-3 days and packed with carton box .

  • Shipping

By courier, door to door
For samples, the package will be delivered by DHL/UPS/FedEx/EMS express. Usually it will take 3-7 days to your location.


Post service
If you are not hurry but need economical delivery, we can go with packet channel. The delivery time depends on your location.


Air shipping or by sea
If bulk order, the packages will be delivered by air shipping or by ship.

FAQ

1) Are you a manufacturer or trade company?
We are manufacturer of PLC,HMI,HMI PLC combo and other industrial products for over 16 years, we have engineers for study & design
and workers for produce and operate etc, we could support you one-stop products and service.
2) Do you have a CE certificate?
Yes for the products we exported, we could offer the CE for your Customs.
3) How long about the delivery?
It depends on the order details, and usually, we could support the delivery within 2-7 working days after payment confirmed.
4) Payment terms:
We accept TT Bank Transfer, Paypal, Credit Card on Alibab, Western Union ect.

Coolmay develops and manufactures HMI, PLC, HMI+PLC all-in-one, modules with Coolmay own brand. We offer services anytime when you need help.
