C11000 Copper Condenser Tube , Petroleum industry Oil Copper Pipe
C11000 Copper Condenser Tube , Petroleum industry Oil Copper Pipe
C11000 Copper Condenser Tube , Petroleum industry Oil Copper Pipe
C11000 Copper Condenser Tube , Petroleum industry Oil Copper Pipe
Specifications
Brand Name :
Transense
Model Number :
CU-DHP;C12000;C11000
Certification :
Rohs
Place of Origin :
Jiangsu, China
MOQ :
1 ton
Price :
USD LME Cu + Fabrication cost
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
400 Tons one month
Delivery Time :
3-4 weeks
Packaging Details :
Bundle and wooden case
Material :
CU-DHP;C12000;C11000
Annealing state :
semi-hard
Standard :
ASTMB68;JISH3300;GB/T19447;EN12735
Surface :
Washed and clean
Alloy or not :
Non-Alloy
Grade :
Copper
Product name :
Copper condenser tube
Warrant :
1 years
Description

Condenser Tube used in petroleum industry and home appliances

Product Description

Copper condenser tube,specially designed for the condenser, the sharp ridges on the radial and axial outside finned section of the tube destroy the surface tension of gas, so as to make the condensing liquid dripping. The tube has high heat transfer coefficient and condensing efficiancy.The Process of Copper Condenser Tube is Extruded processes (Rolling). The fins are formed into the tube wall so the outside diameter of the fins are not larger than the pre-finned smooth tube. Energy Transfer is solely focused on producing the largest variety and most complete solutions for finned tubing.

Application

Copper condenser tube are Widely used in heating systems, Ventilation systems, Refrigeration and climate control systems, Mechanical engineering, Automotive manufacturing and Chemicals and pertrochemical and power plant technology​.

Packing of copper condenser tube Outside: Plywood sea-worthy case or pallet.

Copper Condenser Tube
Item Light tube Wing fragment
O.D. O.D. Wall Thickness minimum Wall Thickness Ridge Height Nominal outside surface area actualoutside surface area Nominal inside surface area Nominal inside surface area
mm mm mm mm mm ㎡/m ㎡/m ㎡/m ㎡/m
1 15.88 15.7 0.635 0.56 0.3 0.0499 0.1733 0.0429 0.0625
2 19.05 18.85 0.635 0.56 0.35 0.0598 0.2282 0.0529 0.0858

C11000 Copper Condenser Tube , Petroleum industry Oil Copper Pipe

C11000 Copper Condenser Tube , Petroleum industry Oil Copper Pipe
