Cu-DHP C12000 Air Conditioning Straight Copper Tube s For The Manufacturing Of Heat Interchange
Cu-DHP C12000 Air Conditioning Straight Copper Tube s For The Manufacturing Of Heat Interchange
Cu-DHP C12000 Air Conditioning Straight Copper Tube s For The Manufacturing Of Heat Interchange
Cu-DHP C12000 Air Conditioning Straight Copper Tube s For The Manufacturing Of Heat Interchange
Specifications
Brand Name :
Transense
Model Number :
CU-DHP;C12000;C11000
Certification :
Rohs;ISO9001;ISO14001;ISO45001;PED4.3
Place of Origin :
Jiangsu, China
MOQ :
1 ton
Price :
USD LME Cu + Fabrication cost
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
400 Tons one month
Delivery Time :
3-4 weeks
Packaging Details :
Bundle and wooden case
Material :
CU-DHP
Annealing state :
Soft
Standard :
ASTMB68;JISH3300;GB/T19447;EN12735
Surface :
Washed and clean
Alloy or not :
Non-Alloy
Grade :
Copper
Product name :
Straight Copper Tube Straight Copper Tube s For The Manufacturing Of Heat Interchange
colour :
Red
Description

Straight Copper Tubes For The Manufacturing Of Heat Interchange

Product Description

Air Conditioning Straight copper Tube,Internal and external surface cleaning,high dimensional accuracy,easy to weld and process,is produced via Horizontal continuous casting technology.Straight Copper Tube produced by our company is mainly used in the connection of heat exchangers and pipeline systems in the air conditioning and refrigeration industries. As the tubes comprise de-oxidized copper, it is not affected through reducing atmosphere.Most commonly supplied in the soft and light annealed form, also straight Copper Tubecan be ordered in hard drawn temper.

Application

Straight Copper Tubes are very cost-effective for the manufacturing of heat interchange, tube bends, fittings, solar collectors, and cable lugs, and electric water heaters. These Coils are primarily for large production runs for industrial operations, and it is widely used in the air conditioning, refrigeration, and heat interchanging field.

Packing: Wooden pallet packing strong seaworthy

Size of Straight Copper Tube
0.2 0.28 0.3 0.35 0.42 0.5 0.61 0.76 0.95 1.2 1.5 2 2.5
4 ■ ■ ■ ■ ■ ■
4.75 ■ ■ ■ ■ ■ ■ ■
5 ■ ■ ■ ■ ■ ■ ■ ■ ■
6~7 ■ ■ ■ ■ ■ ■ ■ ■ ■
7~8 ■ ■ ■ ■ ■ ■ ■ ■ ■
8~10 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
10~13 ■ ■ ■ ■ ■ ■ ■ ■
13~15 ■ ■ ■ ■ ■ ■ ■ ■
15.88 ■ ■ ■ ■ ■ ■ ■ ■
19.05 ■ ■ ■ ■ ■ ■ ■ ■
22 ■ ■ ■ ■ ■ ■ ■ ■
25.4 ■ ■ ■ ■ ■
28 ■ ■ ■ ■ ■

Cu-DHP C12000 Air Conditioning Straight Copper Tube s For The Manufacturing Of Heat Interchange

Cu-DHP C12000 Air Conditioning Straight Copper Tube s For The Manufacturing Of Heat Interchange
