E39/E40 retrofit led corn light allow to replace inefficient traditional bulbs with highly efficient and bright LEDs. These bulbs replace CFL and HID bulbs that range between 40W to 450W. The design of these LEDs allow for 180/360 degree illumination to exactly replcate traditional bulbs in light coverage and color temperature.
* Dual heat dissipation design of the lamp body. Isolated aluminum heat sink and driver, hollow heat sink increase airflow.
* Increase LED plates to 10/12pcs. No lighting shadow, more luminance uniformity.
* Combined heat sink reserve gaps for more ventilation area.
* Suitable to totally enclosed fixture.
* Passed 6000V high voltage surge test, protect the lamp better.
* Good brightness LED with 130lm/w, LM80 certificated.
* More 15% LED compared with general corn bulb in market.
* Fanless design with 5 years warranty.
* The circle ring on the lamp can be customized the color as request.
* UL/cUL/DLC/CE/ROHS/FCC/LM80 certification.
* IES files available.
Product Specifications:
Power | Lumen | Dimension | Voltage | CCT | PF | CRI | Viewing Angle | IP Rating |
45W | 5850lm±100lm | Φ95* 240mm | AC100-300V | 3000K-6000K | >0.9 | >80 | 360° | IP64 |
Materials: |
Others: |
||
LED Brand |
SAMSUNG / EPITSAR |
Base Type |
E26/E27/E39/E40 |
Housing |
6063 Aluminum+Petardant PC |
Safety Certification |
DLC, UL, CUL, CE, RoHS, LM79, LM80 |
Capacitors |
RUBYCON |
Warranty Time |
5 Years |
Glue |
DOW CORNING |
|
Product Installation:
