Corrugated Cardboard Cutting Machine Carton Box Rotary Slotter Machine 100pcs/min
Corrugated Cardboard Cutting Machine Carton Box Rotary Slotter Machine 100pcs/min
Specifications
Brand Name :
Dahua
Model Number :
LD-2500,2600,2800,3000
Certification :
CE,ISO,SGS
Place of Origin :
Hebei
MOQ :
1 Set
Price :
USD 13000-20000 per set
Payment Terms :
T/T, L/C, D/P, Western Union, MoneyGram, D/A
Supply Ability :
50 sets per month
Delivery Time :
25-40 days
Packaging Details :
Export standard package
Feeding way :
Independent Lead edge feeder
Work speed :
80-100pcs/min
Voltage :
220V/380V/440V 50HZ/60HZ
Warranty :
1 Year
Blade Material :
9CrSi
Product Name :
Economic type rotary slotter machine for corrugated carton box
Weight :
6 Tons
Control system :
Electric control by buttons
Description

Corrugated Cardboard Cutting Machine Carton Box Rotary Slotter Machinery

  • 1. This machine adopts the vacuum adsorption lead edge paper feeding style , can once complete slotting, corner cutting, side cutting, creasing and so on.
  • 2. The power motor adopts frequency conversion motor, running smoothly and saving energy.
  • 3. Electric side baffle, electric rear baffle.
  • 4. The slotted phase is adjusted by the planetary gear structure and is adjusted by the electric digital 360degree.
  • 5. Spray lubrication, longer service life of gear transmission.
  • 6. The gear transmission adopts no clearance adjustment design to improve the paper feeding accuracy.
  • 7. Photoelectric counter.
  • 8. Electrical synchronous adjustable slotting knife and creasing wheels togther, easy to adjust, save time and labor.
  • 9.High speed,easy to adjust.

ame of parameter Unit LD-1400 Series LD-1600 series
Max.speed of production pieces/min 100 100
Max.size of paperboard mm 1400X(2000-2800mm) 1600x(2000-2800)
MIx.size of paperboard mm 450X500 550x650
sloting width mm 7 7
Precision of slotting mm ±1 ±1
adaptable thichness of mm 3-11 3-11
Max deepth of slot mm 500mm 550mm
Power kw 15kw 15kw

Lead edge feeding unit

Independent lead edge feeding unit, adopt 4 units of feeding wheels
Max.feeding size 1450 x2500mm
Min feeding size 380x650mm
Wall thickness 50mm
Design speed 120pcs/min
Economic speed 80-100pcs/min

Blades up and down movement by electrical

Blades & creasing movement synchrounous by electric adjustment
