Specifications
Brand Name :
Zhenxing Packaging
Model Number :
SYFC-920/1224/1628
Certification :
CE
Place of Origin :
Hebei, China (Mainland)
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100 Sets Per Year
Delivery Time :
120 days
Packaging Details :
1.Outside package:Sandard export wooden cases 2.Inner package:Stretch film
After sales service provided :
Engineers available to service machinery overseas
Warranty :
1 Year
Machine type :
Printing Slotting Die Cutting Machine
Function :
High Efficiency
Description

Automatic carton box printing slotting die cutting folding gluing machine

.Machine introduction:

  1. This machine is component with the feeding unit,printing unit,slotting unit and die cutting unit,can accomplish the process of the corrugate paperboard printing and slotting or die cutting.
  2. The materials of the body is carbon stell,thickness of body is 60mm,after 20 hours heating treatment ,making by CNC machine,with high strength and high precision.
  3. All the transmission gear is spiral gear,with low noise and high precision,gears after high frequency heating and grinding,adopt automatic circle lubrication.
  4. The gear material is 20CrMnti alloy steel,after high frequency heating and grinding.and the main transmission gear and roller adopt expansion sleeve connection.
  5. Bearing adopt the famous brand made in China like HRB and NSK.
  6. The mail motor adopt frequency converters adjust,the frequency is “Delta” brand made in Taiwan,the PLC also adopt “Delta” brand made in Taiwan,the contactor adopt “Seimens” brand.
  7. The rubber roller adopt JINGYANG rubber roller, famous brand in TaiWan.
  8. Aniloc anilox roller adopt “Haili” brand, famous brand in China.
  9. Main motor is TECO brand Waiwan,adjust motor is Chengbang Brand,Taiwan.

Technical parameters

Parameters Model Model Model
920 1224 1628
Max.speed 250 220 180
Max.sheet width(L) 2000 2400 2800
Min.sheet width(L) 680 720 720
Max.sheet length(H) 1200 1400 1600
Min.sheet length(H) 320 350 400
Max.folding width(A+B) 900 1150 1350
Min.folding width(A+B) 350 350 350
Max.side panel(A) 900 920 920
Min.side panel(A) 210 230 260
Max.end panel(B) 800 900 900
Min.end panel(B) 130 130 140
Max.stacking height 300 300 300
min.stacking height 80 80 80
