150 High Speed Automatic 2 Ply Corrugated Paperboard Production line, 1600MM

1. Product Introduction

Corrugated cardboard production line is the professional equipment for producing corrugated cardboard.

The production line consists of the mill roll stand, preheater, single facer machine, conveyor bridge, computer single facer corrugated cutting and stacker, conveyer and so on.

2. Main units

3. SF-320C Fingerless Single Facer

• Adopt hood suction structure,matched high pressure powerful fan. Gas supply and electrical control cabinet to focus on the same operation, the operating side full cover closed.
• High quality resin sand casting,wall thickness 200mm.Adopt independent gear box, Universal joint transmission structure.
• Install the lifting trolley on the conveyor bridge,Need to use the car will tile roll assembly and pressure roller, such as convenient and quick.
• Glue roller unit structure with the overall relocation,Maintenance can sway the machine at the overall maintenance,improve the working efficiency.
• The humidity control apparatus equipped with a spray, so flute type to maintain good stability of deformation, avoid dry.
• Automatic circulation system for glue, two-cylinder pneumatic gluing device, with good cushioning effect.
• Glue department using integrated slide structure,Glue roller surface after grinding engraved with 25 lines and pit-style textured hard chrome plating.
• Corrugated roller adopt tungsten carbide dealing,diameter of the main corrugated roller¢ 320mm,Quenched→rough car→bore fine boring→shaft head shrunk-on→welding → tempering to stress→fine cars→coarse grinding→IF quenching→CNC grinding machine grinding→Hard chrome plating,hardness of surface is HRC58degrees.

4. Single Corrugated The Aspect Cutter(Spiral Knife Crosscutting,NC thin Knife Slitting,Down Stacking )

• Store 200 groups of orders, the man-machine interface, the screen displays information can be found at any time, modify, append, cancel.
• American Emerson servo motor drive controller, high-performance synchronous servo motor drive.
• Cutting Machine adopts inlaid front steel blade structure, hardened gear grinding backlash-free transmission, high precision and long life.
• Host wall of gray cast iron, rigidity, vibration resistance.
• Stacking adopt gantry platform lifting, Reach a certain number of right-angle transverse. Three sections of the paper,Some hair design paper roll straight bend output,Second overlapping fixed-length buffer,three part points Pneumatic separate. Accelerated export cardboard. Improve working efficiency. The maximum length of stacked is 1.6 meters. This machine is suitable for efficient production color printing business.
• Full servo motor control, change order fast, for a single time 1-3 seconds.Using thin tungsten alloy steel knife,blade sharp,the using life is more than 8000000 meters.
• Brothers for computer-controlled, automatic or manual knife sharpener can be divided trimming knife edge, increase productivity.
• Imported synchronous drive system, precision accurate, long life, low operating noise.
• From high-quality imported industrial computers and high-performance programmable controller configuration, lower computer control system.

5. Photos
