Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
Specifications
Brand Name :
YIKE GROUP
Model Number :
YK-1800
Certification :
CE
Place of Origin :
China
MOQ :
1 set slitter scorer
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 sets per month
Delivery Time :
20 days
Packaging Details :
Plastic Film
Price :
USD 3500
Description

Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine for Making Carton Box

Product Description

structural feature
  • Delta inverter
  • Electric Adjustment Blade
  • Slitting part: adopt high quality tungsten steel blade, sharp and long work-life, slice more tidy, non-pressing and non-burr.
  • Adopt 8 shafts design, two shafts in front and back of the slitter, can minimize the length of paperboard machining to 260mm.
  • 8 shafts with front-scoring feeding,back double rubber rollers for paper leading, running more steady.
  • Scoring part: adopt 5 points scoring, scoring distance in-phase adjust, blazonry and easy to bend the carton sheet.
  • Grinding part: adopt manual type grinding , it could be grinding when working, improve work efficiency. Option: blade pneumatic grinding.
  • Electric adjusted the space of slitter blade and auto pneumatic locking, easy to operate, improve the efficiency.
  • Double guide smooth shafts, operate stably; inlay PU ring seal, clean and dust-proof.

Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box


Regular technical parameters
1,effective width:2000mm

2,The maximum mechanical speed:100m/min
3,Mechanical configuration: 4knives 6lines

Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box

Technical parameter

Model YK-2000 YK-2200 YK-2500
Machine dimension(mm) 3200*1100*2200 3500*1100*2200 3700*1100*2200
Power 7.6kw 7.6kw 7.6kw
Max slitting
width		 Inverse blade 1900mm 2200mm 2300mm
Positive blade 1800mm 2100mm 2200mm
Min slitting
width		 Inverse blade 305mm 305mm 305mm
Positive blade 140mm 140mm 140mm
Min scoring
width		 Positive scoring 30mm 30mm 30mm
Inverse scoring 80mm 80mm 80mm
Scoring height 0-10mm 0-10mm 0-10mm
Blade(mm) φ200*122*1.2 φ200*122*1.2 φ200*122*1.2
Blade & Scoring
Composed Type		 Three blade Four scoring/ Four blade
Six Scoring/ Five Blades Eight scoring

Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box

Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box

Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box

Yk-2000 Electric Adjustable Thin Blade Slitter Scorer Machine For Making Carton Box
