Specifications
Brand Name :
YIKE GROUP
Model Number :
YK-2500
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 Set
Price :
USD17000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30 Sets per Month
Delivery Time :
60 days
Packaging Details :
Plastic Film
Type :
Yk-2500 Thin Blade Slitter Scorer Machine
Key Selling Points :
Thin Blade Slitter Scorer Cutting Creasing Machine
Application :
Machinery & Hardware
QTY of blade/scorer :
5/6/7
Keywords :
Thin Blade Slitter Scorer Machine
Condition :
New
Max.production speed :
200mm
Packaging type :
Corrugated Paperboard Making
Description

Yk-2500 Thin Blade Slitter Scorer Machine Corrugated Carton Making Machine

Yk-2500 Thin Blade Slitter Scorer Machine Corrugated Carton Making Machine

Yk-2500 Thin Blade Slitter Scorer Machine Corrugated Carton Making Machine

Yk-2500 Thin Blade Slitter Scorer Machine Corrugated Carton Making Machine

Human machine interface —PLC control,The system for robot operating system more humanized, simple structure, easy to maintain.

1.Manual/auto feeder is available

2. Pre pressing roller,slitting blade and scorer holder are auto adjusted

3.Grinding knife is auto/manual

4.Cardboard thickness and press power are auto adjusted(customer required)

5.Jog for fine-adjusted

6.Auto counter

7.Slitting and press line precision ±0.5mm

Auto slitter scorer :

8.Human machine interface —PLC control,cutter paper thin blade change order use stand alone stepper motor control,auto change order speed 1-20S,error precision±0.5 mm.

9. Operation humanized.,no technical content,worker use operation use easy.

10 Slitting part:Adopt high quality tungsten steel thin blade,sharp and long work life,slice more tidy,non-pressing and non-burr.

11.The two sides of thin blade are cut separately by rubber wheel press board,surmount not scorer,separate plate,off tracking ,to prevent the bad effect of straight line.

12.This machine can memory 999 group order,don’t need stop machine can change order and manual change order.

13.QR code change orders

TECHNICAL INDEX

Model YK--2500
No.s of slitting scoring 4/6 5/8 6/10
Max.production speed 180m/min 180m/min
Max.feeding width

一刀与二刀最大分切2250mm

The Max.slitting between the two blades:2250mm
Max.slitting width 2600mm
Min.slitting width 200mm
Min.feeding length 200mm
Min.scoring distance

40*135mm
Gap adjustment 手动 Manual
Main motor power 10kw
Dimensions L*W*H 1570*3450*1500mm
Weigh 2780kg
