Lift Type Paper Lamination Machine , High Precision Semi Automatic Flute Laminator
Lift Type Paper Lamination Machine , High Precision Semi Automatic Flute Laminator
Lift Type Paper Lamination Machine , High Precision Semi Automatic Flute Laminator
Lift Type Paper Lamination Machine , High Precision Semi Automatic Flute Laminator
Lift Type Paper Lamination Machine , High Precision Semi Automatic Flute Laminator
Lift Type Paper Lamination Machine , High Precision Semi Automatic Flute Laminator
Specifications
Brand Name :
JCS
Certification :
CE Certification
Place of Origin :
Dongguang County, Cangzhou City, Hebei Province, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Delivery Time :
10 days
Packaging Details :
Wrapped With Film
Packaging Material :
Metal, Paper, Plastic
Effect :
Corrugated paper laminating machine
Machine Type :
Laminating Machine, laminating machine and flip flop machine
Drive Type :
Eletric Drove
Description

Flute Laminating Machine lift type Semi-automatic Type for paper laminator

Main characteristics of automatic flute laminator carton machine

The top paper can pile up the height of 1m once time ,it makes delivery more easier and efficient. Using suction feeding automatic of bottom sheet, according to the main machine operating speed, continuous automatic tracking. The automatic replenishment system of glue can be added. automatically during glue losses, and recycling with the glue to avoid loss of waste. The scientific design of the metering roller speed to ensure the glue evently on the same time, to avoid rejection of glue at high speed., Suitable for color top sheet 175-500g and A/B/C/D/E/F corrugated paper laminating.


Adopt PLC & Taiwan servo motor control system, working is more precision and stable, improved the speed, circuit faults can automatically alarm. Machine uses touch-screen / PLC control system, the circuit system is stable, and can automatically display the failure alarm. The scientific design of the metering roller speed to ensure the glue evently on the same time, to avoid rejection of glue at high speed.

Entire new concept,front gauge registration, position high accuracy, bottom sheet never exceedes the top sheet. Floating removable press, to ensure that laminated paper will not be crushed, and also keep the cardboard smooth and straight; unilateral adjustment by way of adjustment worm roll lamination pressure for quick. Using the rubber roller cleaning to make cleaning thoroughly, and so that the back of the corrugated cardboard never gets glue, and eliminating the trouble of frequent replacement of blade.

Model
1300
1450
1600
Max size
1300 x 1100mm
1450 x 1100mm
1600 x 1400mm
Min size
350 x 350 mm
350 x350mm
450 x 450 mm
Laminate precision
≤±1.5mm
≤±1.5mm
≤±1.5mm
