Working width: Max.2200mm min 1100mm

*Maximum mechanical speed:200mm/min

*Actual running speed:160-180mm/min

*working air pressure:0.6～0.9MPa

*Steam pressure:0.8～1.3MPa

*steam consumption:0.65～1t/h

*temperature requirement:160～200℃

*Total machine power:53.45 kw

*Working power supply: voltage: 380V; frequency: 50Hz

*External dimension: 4400mm×1900mm×2100mm (length × width × height)

Characteristics of the equipment

Hydraulic type, paper guide adopts wind adsorption to maintain the stability of corrugated type at high speed.

* by the fan through the true empty box corrugated paper adsorption in the corrugated roll 180 degrees in the range of negative pressure, to complete the rolling corrugated.

* the width of the lower corrugated roller suction groove is no more than 2.5mm, which can reduce the stripe marks of single-sided corrugated board.

* the transmission part adopts universal joint transmission, isolating vibration source, making the transmission more stable, reliable operation and stronger maintenance.

* the reducer is lubricated with oil, and the closed gear is driven to reduce the vibration of the machine.

* use automatic circulation glue supply, pneumatic glue and reset, with buffer effect.

* the gluing area is electrically adjusted, and the gluing part operates independently when the machine stops to prevent the paste from being exhausted.

* the surface of the cots has been specially embossed and chrome plated.

* the rubber coating part is driven separately and can be pulled out for convenient maintenance and cleaning.

* corrugated rolling part of separate small wall board design, tile roll easy to remove, maintenance, replacement of the corrugated type is convenient and fast.

* upper and lower corrugated roller is made of high quality alloy steel, after heat treatment, hardness in HRC 56-60 degrees.
