Technical parameter

Characteristics

*Special structure design, high tensile strength wall plate and seat, there are watching window on wall plate two sides, convenient and easy to maintain.

* Transmitting system adopts oil pump auto-cycling lubricating, make sure transmitting precision.

*Adopting high precision, high rigidity whetted gears, bearing high running and durable, make sure blade-edge joggle exactly, cardboard is level off and clean

*high precision shaft, blade carrier design, cutting stably when machine high speed running

*Special changing blade structure, quickly and easily changing blade

*The system is made according to C.E. standard, and has been strictly tested by industry computer. The quality, life, and stability can be guaranteed.

*Driving unit adopts A.C. Servo drive, quickly and exactly acts.

*Special electricity structure design, more saving electricity, can avoid the problems of not stable electricity.

*Adopts special power bring and storage type design, save electric and could overcome electric voltage not steady environment.

*System has self test function, can prevent machine loss because of abnormal usage and false operation

* Computer automatically adjusts cutting speed according to cardboard specifications and production speed, automatically follow cardboard running speed, assure in –phase.

* Computer reserves 999 groups of order, and auto-complete based on the program and preferential condition, the screen display various production message.

*Cutting length: 500~9999mm,cutting precision :±1mm.

*Rotary blade is made in Tainwan

*Shaft bearings are from NSK, Japan, suitable for machine high speed running, durable.

Raw materials and bought-in parts

Wall plates two sides and seat:20# steel Origin: Hebei

Upper lower shaft: 45# steel

Balde:W18crv5Co5(high speed tool steel)

Gear:40Cr whetted, quenched and tempered

Main drive engine(AC. servo)power: 45kw, 1set Origin: China

Transmitting cardboard engine power: 2.2kw 2sets, Origin: China

Oil pump engine power: 0.19kw 2set Origin: China

Computer control system

Bearing: (main) NSK Japan (common) China

Pneumatic parts: Yadeke Taiwan, Tianyuan Shandong
