250kw Corrugated Cardboard Making Machine Width 1400mm-2500mm Electricity 380V 50Hz
250kw Corrugated Cardboard Making Machine Width 1400mm-2500mm Electricity 380V 50Hz
250kw Corrugated Cardboard Making Machine Width 1400mm-2500mm Electricity 380V 50Hz
250kw Corrugated Cardboard Making Machine Width 1400mm-2500mm Electricity 380V 50Hz
250kw Corrugated Cardboard Making Machine Width 1400mm-2500mm Electricity 380V 50Hz
250kw Corrugated Cardboard Making Machine Width 1400mm-2500mm Electricity 380V 50Hz
250kw Corrugated Cardboard Making Machine Width 1400mm-2500mm Electricity 380V 50Hz
250kw Corrugated Cardboard Making Machine Width 1400mm-2500mm Electricity 380V 50Hz
250kw Corrugated Cardboard Making Machine Width 1400mm-2500mm Electricity 380V 50Hz
250kw Corrugated Cardboard Making Machine Width 1400mm-2500mm Electricity 380V 50Hz
Specifications
Brand Name :
Quanheng
Model Number :
1800-5
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1set
Price :
Negotiate
Payment Terms :
L/C, T/T
Supply Ability :
10set per year
Delivery Time :
120 working days
Packaging Details :
stardard
Color :
Stardard
used :
carton box making line
package :
film
power :
250kw
Warranty :
12month
Condition :
new
name :
Corrugated cardboard making machine
Description

QHCL-1800-200-5PLY Corrugated Cardboard Production Line

Equipment name
Hydraulic shaftless mill roll stand
Paper trolley
Top paper preheat cylinder
Core paper preheat cylinder
Fingerless type single facer
Triple preheater
Double glue machine
heavy type conveyor bridge
Double facer
NCBD thin blade slitter scorer
NC cutter helical knives
computer gantry automatic stacking machine
Glue station system
Gas source system
Steam system
Electrical control cabinet system

1. Manufacture width: 1400mm-2500mm

2. Design speed: 200m/min Working speed:140-180m/min

3. Note: The roll paper which is used to test the production speed should meet following requirements:

* Grade: Min. B * Moisture content: 11% ± 2%

* Face paper: 100~250g/m2 * Liner paper: 100~150g/m2

* Corrugated paper: 100- 200g/m2

4. Flute profiles: A,B,C ,E flute(as per clients request)

5. Steam requirements

Steam consumption:4000kg/h Air compressor pressure:0.8~1.1Mpa

6. Electricity: 380V, 50Hz,three-phase four wire type

7. Equipment Direction:Left or Right transmission will be according to client’s requirements.

8. Factory request size:specific length as to the foundation of drawing
