Case maker 5 Colors Flexo Printer Slotter Die Cutter Folder Gluer in-line

1, The machine clutch

1) Electric control machine clutch attached to an alarm, warning road between the continuous ringing, to ensure the safety of workers.

2) Each plane between China and Taiwan, the device has emergency stop switch, an internal control to stop the machine moves to ensure the security of the internal operations personnel.

3) The the pneumatic interlock device.

4),The whole total of lock.

2,Dust removal system

1). Equipped with 171mm diameter high effective brush roller and rows of brushes dust removal device.

2). 5.5Kw big flow dust exhaust fan.

3). Equipped with DC monolithic air exhaust ion stick electrostatic dust removal device. The above multiple trash dust removal system makes trash and dust removal thoroughly, cardboard surface is more cleaner, greatly improve printing quality.

3,Feeding system

1)One set of feeding roller: feeding roller outer diameter is 154.3 mm(upper feeding roller), high quality alloy solid steel wrapped with wearable rubber, Static and dynamic balance correction

2)Lower feeding roller 162 mm, embossing and hard chrome plating, static and dynamic balance correction.

Printing unit (ceramic anilox roller,Doctor blade)

vacuum suction transmission

1.Printer roller

1)The plate roller shaft quenched, all tube addition to the stress tempered.

3)Dynamic and static balance correction, smooth operation.

4)Surface grinding, hard chrome plating.

5)Ratchet fixed reel printer plate axis.

6)The use of hanging mechanism is convenient, fast, for 10mm hanging version of the article.

7)Loading and unloading printing plate, foot switch electric control reversing.

2.Embossing roller

1)The embossing roller head quenched, full tube addition to the stress tempered.

2)Pipe inner surface of the deep hole boring and full processing.

3)The surface grinding, hard chrome plating.

4)Dynamic balance correction, smooth operation.

5)The printing nip Worm electric adjustment, digital display, the adjustment range of 0-12mm.

3,Anilox roller

1)The inner surface throughout the processing, the physical consistency.

2)The surface of the steel pipe after special processing sprayed ceramic laser engraving textured.

3)Dot, even on ink, durable, and durable.

4)Extended the plate and rubber roll life.

5)Dynamic balance correction.

6)The anilox roller with quick-change structure, convenient maintenance and maintenance of the machine.

4,(ceramic anilox roller,Doctor blade)

1)Ceramic mesh roller with semi-closed scraper.

2)Scraper system adopts American technology, fine printing, ultra-low loss.

3)Preventing volatilization is more environmentally friendly.

4) Ink-touching plate adjustment of reticulated roll is pneumatic down-pressing action, automatic hoisting protection device when air stops, and transmission gear center remains unchanged.

5)Trace adjustment of clearance between screen roller and plate wheel.

6)Automatic induction ink detection system, including warning lights and alarm bells.

7)Ink pump is a single diaphragm pneumatic pump, which can recover the accumulated water filter and ink circulating system inside and inside the pump.

8)The cartridge is quickly disassembled and the inner surface is sprayed with Teflon to improve the cleaning efficiency.

9)Closed cover and recycling ink tank device, easy to clean and leak-proof design.

10)Introduction of scraper

Slotting unit(full computer control)

1, planetary wheel phase adjustment, positive and negative 360 degrees electric operation adjustment.

2, Carton length width height adjustment by computer control.

3, The front knife position to the automatic zero, zero after the linkage of the seat before the axial displacement.

4, When the Back knife Circumferential movement independently, to adjust the height of the carton, box high electric adjustment.

5, Linkage plates are made by Machining center

6, the linkage plate sliding has the diameter of 100mm linear slide way, less resistance, precise movement.

7, The upper and lower screw rod synchronous transmission adopts spiral gears, and the transmission is reliable and convenient to be installed, which can eliminate the gap and drive accurately.

Die cutting unit

1.Roller is high quality steel surface hard chromium plating,correcting and drilling balancing,Increase the stability and reliability of its operation.

2,Die roller and soft roller adopt International standard size, add up die mould diameter is 310mm,soft roller diameter is 281mm(Rubber sleeve diameter is 297mm),Can be in any place to buy the right template and rubber gasket .

3,knife die mould roller and rubber pad roller gap adopt manual adjustment .

4,die cutting roller phase adopt planet structure,High precision , large bearing capacity , stop , can be 360 ° electric digital adjustment operation

VIDEO LINK:http://www.corrugatedcardboardmakingmachine.comhttps://www.youtube.com/watch?v=ebx-Iz0XPF8
