1 Year Warranty Flute Laminating Machine For 1 - 12mm Corrugated Paper
1 Year Warranty Flute Laminating Machine For 1 - 12mm Corrugated Paper
1 Year Warranty Flute Laminating Machine For 1 - 12mm Corrugated Paper
1 Year Warranty Flute Laminating Machine For 1 - 12mm Corrugated Paper
Specifications
Brand Name :
ZHAOLI
Model Number :
HL-1300
Certification :
CE
Place of Origin :
HEBEI PROVINCE , CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10 sets / month
Delivery Time :
20-30 days
Packaging Details :
plastic film packing and load to the container and fixed with steel wire rope or with steel packing
product name :
high speed flute laminating machine for 1-12mm corrugated paper
process width :
1300mm , 1450mm , 1600mm
warranty :
1 year for whole machine
function :
for paper laminating
working speed :
9000 sheets/h
payment :
T/T
Description

high speed flute laminating machine for 1-12mm corrugated paper

Main Characteristics

  • Adopting back pusher , back positioning feeding , equipped with spring side lay and bottom suction system , to make our machine suitable for all kinds of paper , and keep the good characteristics of easy operation and convenient maintain .
  • The glue roller adopts high design , match with anilox to glue distributing , the uniformity of coating was improved greatly, increasing the intensity of draping , reduce the cost of customer production .
  • The steel roller through the balanced treatment and test , match the tight assembling to make higher stability . And adopting the timing belt and tooth type belt driving , make the machine running with higher precision and lower noise.
  • Adopting the liquid control system , automatic gluing , and the glue can be cycle used , avoid glue waste and labor strength .
  • Self-developed high-strength feeder with high configuration electric system make the machine running stable and lower failure rate, the electric parts adopt international wide available brand or well-known Chinese brand.
  • This machine bottom paper is suitable for A, B , C, D, E, F flute . It can do 3 layer, 5 layer board to sheet laminating or thick board to board laminating . The surface paper need 200-600 GSM . With top paper advance and alignment function .

Technological Parameter

Model HL-1300A-IV
Max Laminating Size ( W×L ) 1300mm*1100mm
Min Laminating Size ( W×L ) 350mm*350mm
Economical Speed 6000 sheets/h
Laminating Precision ≦+/- 1.5mm
Total Power 12 kw
Machine Length 12.5m
Machine Weight 6.8 tons

1 Year Warranty Flute Laminating Machine For 1 - 12mm Corrugated Paper
