Corrugated Cardboard Partition Assembly Machines With Electric Driven
Corrugated Cardboard Partition Assembly Machines With Electric Driven
Corrugated Cardboard Partition Assembly Machines With Electric Driven
Corrugated Cardboard Partition Assembly Machines With Electric Driven
Corrugated Cardboard Partition Assembly Machines With Electric Driven
Corrugated Cardboard Partition Assembly Machines With Electric Driven
Corrugated Cardboard Partition Assembly Machines With Electric Driven
Corrugated Cardboard Partition Assembly Machines With Electric Driven
Corrugated Cardboard Partition Assembly Machines With Electric Driven
Corrugated Cardboard Partition Assembly Machines With Electric Driven
Corrugated Cardboard Partition Assembly Machines With Electric Driven
Corrugated Cardboard Partition Assembly Machines With Electric Driven
Specifications
Brand Name :
ZHAOLI
Model Number :
500 Model
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
20,000 USD
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10 sets/Month
Delivery Time :
30 days
Packaging Details :
plastic film
Automatic grade :
Automatic
Type :
automatic cardboard assemble partition machine
Voltage :
220V/380V
Application :
Machinery & Hardware
Driven type :
Electric
Condition :
New
Packaging material :
Plastic
Packaging type :
Film
Function :
carton package machine
Product name :
Partition Assemble Machine
Usage :
Partition Cardbordboard Assembler Machine
Description

Corrugated Cardboard Partition Assembly Machines With Electric Driven

Technological Parameters :

Power supply 380V/50HZ, 3 phases, or we can produce as customer request
Power 10 kw (not including the air compressor)
Host belt speed 15-30 m/min
Working speed 30-60 groups/min
Clapboard combining form 3*(1-N), in double working station
Longitudinal clapboard feeding track number 6 pieces
Horizontal clapboard feeding track number 1-12 pieces
Clapboard Length 120-450 mm
Clapboard Height 75-200mm
Clapboard width

120-450mm, double station

120-900mm, single station
Lattice spacing Horizontal:40-150mm; Longitudina: 30-150mm
Machine weight 3 tons
Overall dimension 5500x2200x2000mm

Feature:

BL450 type automatic partition assembler machine is optimized to be a new partition assembler devices on the basis of absorbing the advantages of equipments at home and abroad in our factory. The equipment takes the place of the traditional manual operation mode, automatic complete insertion of clapboard, saving labor costs, effectively improve the production efficiency at the same time. It is the ideal packaging equipment of fruit and vegetable, glass, ceramic, plastic and so on.

Function:

1. Suitable for the auto insertion of all kinds of carton clapboard

2. Longitudinal and transverse to cross the two pieces of paper at the same time

3. Output in double work positions, high efficiency and energy saving

4. Touch screen input control, simple operation
