ML Platen Die Cutting And Creasing Machine For Die Cutting Cardboard
ML Platen Die Cutting And Creasing Machine For Die Cutting Cardboard
Specifications
Brand Name :
zhaoli
Model Number :
zl1500mm
Certification :
CE
Place of Origin :
HEBEI CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
Western Union
Supply Ability :
100set per month
Delivery Time :
15 days after get diposit
Packaging Details :
plastic fit the ocean shipment
Name :
flat die cuter
color :
gray
model :
1500mm
Description

ML Platen Die Cutting And Creasing Machine For Cartons

1.high quality alloy copper, thus to get effect of anti-frietion and shake reducing.
2.High strength due to one piece casting by using top-ranking material for machine body.
3.Single plate electromagnetic clutch is sensitive and reliable.
4.With functions of single, continuous and opening dwell operation, dwell range is adjustable.

5.Flywheel torque is big, so the pressure is larger.
6. Operating position is reasonably arranged, moving-bed can be opened to its optimum.
7.Safety system is reliable, the machine has four safety point, when you touch this four places, the machine will stop.

Main specification:

Model Max rule area Speed Max Rule Length Motor Power Weight Dimension
ML750 750x520 28±2 <15m 2.2kw 2000kg 1260x1350x1280
ML930 930x670 23±2 <25m 4.0kw 3000 1800x1600x1600
ML1100 1100x800 20±2 <32m 5.5kw 4500 1900x1800x1700
ML1200 1200x830 20±2 <35m 5.5kw 4800 1900x2000x1700
ML1300 1300x920 18±2 <40m 5.5kw 6000 2000x2400x1800
ML1400 1400x1000 18±2 <45m 5.5kw 6500 2000x2450x1900
ML150 1500x1050 18±2 <45m 5.5kw 6500 2000x2500x1930

Four safety, when you touch this four place, the machine will stop, it is very safe.

ML Platen Die Cutting And Creasing Machine For Die Cutting Cardboard

ML Platen Die Cutting And Creasing Machine For Die Cutting Cardboard
