Corrugated Manual Carton Die Cutting Machine Easy To Operate Blue Color
Corrugated Manual Carton Die Cutting Machine Easy To Operate Blue Color
Specifications
Brand Name :
Zhaoli
Model Number :
1600
Certification :
CE
Place of Origin :
China
MOQ :
one
Payment Terms :
L/C, T/T
Supply Ability :
one set per 30 days
Delivery Time :
one week
Packaging Details :
Pplastic
The noise level does not exceed :
70B
The type of administration :
Manual
Clutch :
Electromagnetic
Operating mode :
Continuous, single, continuous open on time.
Speed :
20 impact / min.
The length of the cutting and creasing :
<35 m
Description

Corrugated Carton Blue Color User Manual Die Cutting Easy To Operate Machine

The main structure of the machine is composed of the movable platen, magnetic clutch pressure and electrical control panel.. The engine is positioned to the right side of the machine behind the flywheel gear which is coupled to the V-belt pulley. Under the influence of the pressure of magnetic clutch, the transmission shaft is coupled with the flywheel gear and rotates or stops. Then reduce the speed of traffic through three gears, thus both gears rotate the motor shaft end at slow speed and movement of the arm connecting mechanism with the platen and machine performs the function of cutting and creasing.

Type Specification
The area of plate 1200*830mm

Adjustment - closing time

0-6 seconds

Engine

 5.5KW

dimensions of the machine

1900x2000x1700mm
Weight 4800kg

Control distance of the plate

 47mm
