Corrugated Binding Carton Box Strapping Machine 850x600
Corrugated Binding Carton Box Strapping Machine 850x600
Corrugated Binding Carton Box Strapping Machine 850x600
Corrugated Binding Carton Box Strapping Machine 850x600
Corrugated Binding Carton Box Strapping Machine 850x600
Corrugated Binding Carton Box Strapping Machine 850x600
Corrugated Binding Carton Box Strapping Machine 850x600
Corrugated Binding Carton Box Strapping Machine 850x600
Specifications
Brand Name :
IPACK
Model Number :
800
Certification :
CE,ISO
Place of Origin :
Hebei province,China
MOQ :
1 sets
Price :
To be negotiated
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30 sets/month
Delivery Time :
15-20days
Packaging Details :
Wooden case packaging(optional) or well packed plastic film packaing
Automatic grade :
Semi-Automatic
Condition :
New
After-sales service provided :
Engineers available to service machinery overseas,Overseas service center available,Overseas third-party support available,Online support
Type :
strapping machine,PE bunding machine
Warranty :
One year for free
Product name :
carton strapping machine
Function :
Packing Strapping,cartons strapping
Size :
850x600
Packaging type :
Film
Description

Automatic Corrugated Carton Box PP Belt Carton/Case /Box Binding Strapping Machine

Introduction

The corrugated cardboard box binding line is suitable for the finishing and packing of the back

of the automatic glue box machine,which has the advantages of saving manpower, saving time and labor.
Capacity: 15-20 bales/min (Normal 20 pcs/ bale)
Working environment: Relative humidity < or equal 90%; Temperature 0-40 degrees Celsius;

Noise < or equal 75dB (A);
With of Band: 5mm
Specification of band reel: Inner diameter of band paper core is 200mm-210mm, diameter of band

reel 400-450mm, Width of band175 -190mm
Gluing method: heat fusion;
Bonding type: bottom bonding, the bonding surface is more or equal 90%, the bonding position

deviation is less than or equal to 2mm;
Strapping tension strength: 0-45Kg;
Air pressure: 0.5-0.8MPa;
Roller material: stainless steel; diameter: 50mm; thickness: 1.5mm;
Conveying speed: 0-50m/min

Corrugated Binding Carton Box Strapping Machine 850x600

Corrugated Binding Carton Box Strapping Machine 850x600

Parameters

Model DB-0860AC
Electrical 1PH,110V/220V,50HZ60HZ
Power consumption 950W
Warm-up time 180s
Strap width 8-19mm(fix)
PP strap paper coil I.D 8’’(200mm)
Tension adjustment 0-70kgs
Strapping speed 2.4s/pcs (25pcs/min)
Arch aluminum arch
Arch size W:850×H:600mm
Min. strapping size W:100×H:30mm
Max. strapping size W:850×H:585mm
Working table height 814mm
Machine dimension(L×W×H) 1420×633×1520mm
Wooden size (L×W×H)

Arch assembled 1476×689×1644mm

arch disassembled 1476×829×999
Machine weight 280kgs

Detailed Images

Corrugated Binding Carton Box Strapping Machine 850x600

Packing and Shipping

Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road

transportation and various types of weather conditions. A full set of maintenance and operation

manuals is included.

Corrugated Binding Carton Box Strapping Machine 850x600
Our Services

Q: 1.Are you a manufacturer, trading company or a third party?

A: We are a manufacturer, [Cangzhou Shengchuan Machinery Manufacturing Co.,Ltd] located in Xiaoxing Industrial zone,south of Dongguang county, Hebei province, China. Warmly welcome to visit our company.

Q: 2. What is your minimum order quantity, can you send me samples?

A: Our minimum quantity is 1 set, as our product is machinery equipment, it’s difficult to send you samples, if you have any questions about the products, please feel free to contact us for more detail, we are glad to provide you more information such as specifications, video, etc.

Q: 3. How does your factory do regarding quality controlling?

A: (1) All raw material we used are environmental-friendly.

(2) Skillful workers care every details in handling the producing and packing process.

(3) Quality control department are specially responsible for quality in each process.

We have been kept providing high quality products by introducing advanced technologies for over 20 years, and our products are also widely exported to many different countries including Russia, the Middle East, Africa, Southeast Asia, EU, etc, which earned us a high reputation among the customers.

Q: 4.What is the delivery time of your machine?

A: In general, the delivery time of our machine is about 30 days, customized machine will be delivered as the negotiation with our clients.

Q: 5.How about the after-sale service?

A: (1) TM online for 24 hours, also contact by email, skype, MSN, whatsapp, etc.

(2) To solve the problems with videos/pictures.

(3) One year warranty for spare parts change.

Customized

Corrugated Binding Carton Box Strapping Machine 850x600
