Flexo Folding Gluer Carton Production Line

Max running speed:350m/min

Max packaging speed:20packages/min

Purpose and Features:

• CNC control system, fault display, production control, remote maintenance.
• Automatic detection and positioning system, fast plate loading drive system, quick plate change.
• Widened dust box, anti-static device, central dust collection, pressure protection, effective dust removal.
• Adopts alloy steel precision ground gears for suction wheel transmission and drive to ensure accuracy and longevity.
• Double-seat "forming, slotting" with precise guiding and regulating wheel system, explosion-proof wire, excellent folding and forming effects.
• "Up and down" high-speed paper stacking and recycling collection system, protecting against surface abrasion, high production efficiency.
• Electrical components, transmission bearings, etc., use international brands, certified by European CE.

Counting Output Unit:

• "Up and down" collection system to effectively protect against surface abrasion, high production adaptability.
• High-frequency box correction, fan-assisted paper dropping, pneumatic flattening, circulating transmission.
• Multi-servo drive control high-speed counting stacking recycling collection system, ensuring high productivity.
• Conveyor belt output for counting unit, paper pressing roller assist, electrically adjustable paper gap.
• Horizontal movement electric adjustment for counting output unit.

Folding Unit:

• Extended high-strength folding box bridge arm to ensure folding accuracy and high-speed stability.
• Uses linear guide synchronous lateral movement system, with a high-strength bridge support in the middle for smooth displacement.
• Elastic guiding roller system with adjustable clearance, protecting against compression damage, effectively solving paper jam issues.
• Folding shaping guiding wheel system, with guide bars for assistance, good folding effect with upper and lower belt clamping conveyance.
• Rear suction belt transmission, independently driven motor on both sides for correcting deviations effectively.

Transfer Unit:

• CNC linked control, convenient and fast adjustment.
• Elastic guiding pressure roller device, upper and lower belt clamping transmission.
• Multiple debris removal devices: air knife, brush, electric roller brush, excellent debris removal effect.
• Constant temperature adjustable gluing system, maintaining consistent glue temperature for optimal bonding characteristics.
• Mesh hole large glue wheel system, stable gluing, controlled glue amount, electrically adjustable position.

Features of equipment:

• Introduction
• 1. All paper conveying belts can be moved independently. The paper conveying belts are equipped with paper pressing wheels, fans, and brushes to clean up the waste paper to the greatest extent. Guide wheel device, upper and lower belt clamping transmission. Electric left and right walking, easy to adjust the size
• 2. Gluing wheel: Made of stainless steel, more durable and corrosion-resistant. The glue hopper is equipped with linear guides, making position adjustment more convenient and accurate.
• 3. Folding part: The main function is to fold the carton down, and use the correction plate to correct the pressure line for the second time to fold the carton into a standard box.
• 4. For molding cleaning, if the scraping part and folding part have not been cleaned up, the waste paper scraps will be cleaned again.

• 5. Pat the parts together: Pat the points together, and push them out with an accurate number through counting light, counting, and correction.
• 6. Output part: After pushing out, the above paper holder presses smoothly for output.

Mechanical configuration of packaging department:

(1), Taizhou Haoli reducer

(2), AirTAC cylinder, solenoid valve

(3), Guangdong Duffy power transmission shaft

(4), Bearing Harbin

Electrical configuration:

(1), Panasonic PLC

(2), Siemens contactor

(3), Schneider button

(4), switching power supply: Taiwan MEAN WELL

(5), Photoelectric switch Beifuning

(6), Relay Omron

(7) Human-machine interface Kunlun Tongtai

• 8. Control panel; adopts PLC control and has functions such as zeroing and memory. (PLC combined with touch screen control can be selected)
• 9. The controller panel for each action of the machine controls the left and right movement, the rise and fall of the paper platen, etc
