2BV 2880Rpm Electric Vacuum Water Ring Pump Corrugated Machine Spare Parts
2BV 2880Rpm Electric Vacuum Water Ring Pump Corrugated Machine Spare Parts
Specifications
Brand Name :
Lycorrugated
Model Number :
2BV
Certification :
CE, ISO, TUV, SGS
Place of Origin :
Foshan,Guangdong
MOQ :
1 Set
Price :
Factory Price
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000 Piece/Pieces per Month
Delivery Time :
5-9 work days
Packaging Details :
Carton
Power :
2.35kw
Specification :
SKA2060/2061/2070/2071
Rated Flow Rate :
79.8
Inlet Size :
40
Ultimate Vacuum :
33Mpa
Connection :
Threaded Connection
Description

2BV 2880Rpm Electric Water Ring Vacuum Pump Corrugated Machine Spare Parts

Product Parameter:

Model

Vacuum Pressure

Mbar(Pa)

Air Flow Rate

M3/min

Capacity

KW

Rotating Speed

Rpm

Water Consumption

L/min

 Noise dB(A) Weight Kg
2060 33(3300) 0.45 0.83 2880 ~2 62 20
2061 33(3300) 0.87 1.45 2880 ~2 65 22
2070 33(3300) 1.33 2.35 2880 ~2.5 66 31
2071 33(3300) 1.83 3.85 2880 ~4.2 72 42

Use and maintenance:

1, 2BV type water ring vacuum pump In order to make the wear impeller, pump body or stuck impeller not easy to wear, with gas and working fluid into the pump cavity dust particles, can be washed away through the 2BV type water ring vacuum pump bottom flushing port.

2. If hard water is used as a working liquid, it must be softened or the pump must be cleaned with a solution during the cycle.

3, 2BV type water ring vacuum pump motor often work bearings than the surrounding temperature of 15 °C ~ 20 °C, not allowed to pass 55 °C ~ 60 °C, normal work of the bearing should be oiled 1-2 times a year, at least once a year to clean the bearing, and replace the lubricating oil.

4, 2BV type water ring vacuum pump using the mechanical seal, leakage phenomenon, should check whether the mechanical seal of the dynamic, static ring has been damaged, or the sealing ring has been aging, such as the above situation, need to replace the accessories.
