Models | CPL5000 | | |
Battery | Nominal Voltage | 51.2V | |
| Voltage Range | 45~57.6V | |
| Capacity | 5000WH | |
| Max.discharge Rate | 1C | |
| Max.charge Rate | 1C | |
| Battery Type | Li-ion(LFP) | |
AC Output | Rated Power | 5000W | |
| Surge Power | 10000W | |
| Output Voltage | 220/230/240Vac | |
| Output Current | 22A | |
| Rated Frequency | 50/60Hz | |
| VTHD | <3% | |
| Output Wave | Pure Sine Wave | |
| Output Type | Euro Round AC Socket×2 ; 48Vdc Socket×1(Anderson 100A) | |
| Max. Efficiency | 93% | |
AC Input | AC Input Voltage Range | 170~280Vac | |
| AC Input Frequency | 50/60Hz | |
| Max AC Charge Current(Battery) | 30A(0~60A Adjustable) | |
| Max. Efficiency | 93% | |
PV Input | Max. PV Power(Recommended) | 4000W | |
| Max. PV Voltage | 450V | |
| MPPT Range | 120V~430V | |
| Max PV Charge Current(Battery) | 80A | |
Operating Conditions | Operating Temperature | 0~55℃ | |
| Storage Temperature | -15℃~60℃ | |
| Humidity | 5%~95% | |
| Cooling Strategy | Fan | |
| Weight | 78kg | |
| Dimension [W x H x D] | TBD | |
| Packing | wooden case | |
| Packing Dimension [W x H x D] | TBD | |
| Enclosure Protection Rating | IP20 | |
| Communication | WIFI/RS485 | |
| Warranty | 2 years |
