Specifications
Brand Name :
Terry
Certification :
CE ISO9001
Place of Origin :
Jiangsu, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5 sets per month
Delivery Time :
10-15 days
Packaging Details :
Our products are packed in boxs.We will check that if the machine can run before it is sent out.When you receive the goods,please open the package to check out if the goods are in good condition before the courier.If the boxs are damaged or other situation
Model Number :
8 Heads Dishwashing Liquid Filling Machine With High Speed Servo Motor Driven
Application :
8 Heads Dishwashing Liquid Filling Machine With High Speed Servo Motor Driven
Filling speed :
60BPM
Filling range :
300-3000mL
Key Selling Points :
Servo Quantitative Filling
Description

8 Heads Dishwashing Liquid Filling Machine With High Speed Servo Motor Driven

8 Heads Dishwashing Liquid Filling Machine With High Speed Servo Motor Driven

1. Whole line power: about 17KW, AC380V, whole line gas consumption: about 400L/min

2. Production speed of the whole line: 80-100 bottles/minute (taking 500ml product as an example, the specific production capacity depends on material characteristics, packaging conditions, and operational proficiency)

3. The whole line has a high degree of automation, and production operations can be easily completed by only 2-3 people.

Application Daily chemical products,Baby cleanser Shampoo bady care Body milk bath milk hair conditioner
Filling head number
 8 Heads
Filling range
300-3000ml (Multiple specifications are available)
Filling accuracy
301-500ml±2g ；501-1000ml±3g；1001-3000ml±4g
Applicable bottle type
Bottle size (Φ 50mm- φ118mm); bottle shoulder height (80mm-250mm) Can be customized according to the customer packaging materials
production capacity
≥60 bottles / min (300ml as example) ≥50 bottles / min (2000ml as example) (Production capacity depends on the packaging material conditions and operation proficiency)
Air pconsumption
0.6 ~0.8Mpa (Dry, clean compressed air shall be used)
source
AC380V, 50Hz (three-phase five-wire system)
Dimension(L*W*H)
2200×1500×2300mm
Weight About 2,000 KG

1. Unlimited bottle type: Designed in a following mode, automated production can be completed by simply standing the bottle, without the need for a bottle mold.

2. No scratches on the bottle body: During the filling process, there is no contact between the bottles to ensure no scratches. The use of molds increases the risk of secondary scratches.

3. There are no replacement parts, and the replacement specifications only need to be adjusted intelligently with one button: the replacement bottle type does not require replacement parts, and each filling unit is controlled separately, which can be adjusted with one button on the touch screen.

4. Low loss: There are a total of 10 sets of piston cylinders, 10 sets of filling hoses, and 10 sets of filling heads in the entire machine. When switching product specifications, this component saves material loss compared to the multi head filling machine.

5. The whole line has a strong sense of technology and good accessibility: all are designed in a following mode, with good visual and sensory effects. Equipped with intelligent robots for operation, it is more technologically pleasing and accessible.

Packing:
8 Heads Dishwashing Liquid Filling Machine With High Speed Servo Motor Driven

About us:
The first of China;The leading of world;The best of national brand
FAQ:

Q1. Can we customize it??

A: Yes, We can customize according to your requirements and production capacity. Flexible production line.

Q2. What about the lead time?

A:Some machines are shipped within 7 days, and samples can be sent for free testing.

Q3: What kind of payments do you accept?

A:T/T, L/C, Western Union, etc..

Q4: Do you offer guarantee for the products?

A: Yes, we offer 1 year warranty to our products,All accessories damaged within one year (except for human damage) will be borne by our company, including freight.

Q5: What's the MOQ?

A:MOQ is 1 set.

Contact:Cyn.wu

Wechat/Whatsapp:0086-13921010106

8 Heads Dishwashing Liquid Filling Machine With High Speed Servo Motor Driven
