AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
Specifications
Brand Name :
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
Certification :
CE ISO9001
Place of Origin :
Jiangsu, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5 sets per month
Delivery Time :
10-15 days
Packaging Details :
Our products are packed in boxs.We will check that if the machine can run before it is sent out.When you receive the goods,please open the package to check out if the goods are in good condition before the courier.If the boxs are damaged or other situation
Model Number :
Terry
Application :
AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa
Type :
packing machine
Advantage :
Efficiency
Filling speed :
75BPM
Operation :
Automatic Operation
Description

Stable Filling Speed and Small Gas Consumption Oral Liquid Filling Machine

AC380V 50Hz Oral Liquid Filling And sealing Machine 0.6-0.8Mpa

1. Material and design differentiation
Advanced material selection: Use hose materials of higher quality or special functions, such as heat-resistant, chemically resistant, or environmentally friendly materials. This can attract customers who have higher requirements for product quality.
Customized design: Provide hoses of different sizes and shapes to meet the needs of various specific applications. This diversity can cover a wider range of market demands and enhance the market competitiveness of products.

1 Applicable materials Plastic pipe, aluminum-plastic composite pipe
2 Filling range

2ml-400ml

*The filling capacity range varies depending on the physical properties of the raw materials and the feeding device.
3 Production speed

60pie/min(Take 50ml product as an example)

*Actual production capacity varies depending on product size, packaging material, material characteristics, etc.
4 Filling accuracy

≤±0.5%

*Measuring accuracy varies depending on material characteristics, filling volume and feeding device.
5 Applicable pipe diameter Φ13-Φ50mm
6 Applicable pipe length 70(No cover included)-230mm(Covered)
7 Material box volume 45L
8 Applicable material viscosity 60000CPS(Based on standard plunger pump)
9 power supply AC 380V
10 monitor rate 4.5KW
11 working pressure

0.6 ~0.8Mpa

(Dry, clean compressed air must be used)
12 Air consumption 50L/Min
13 weight 700Kg
14 Dimensions 1920*1083*2100mm(L*W*H)

Features

1. Tube filling and sealing machine is mainly used for primary transmission principle;
2. Using imported sensors and other electrical components control, a change of the old model of pneumatic control components, not easy to abrasion;

3. The rotary table equipped with fixture is driven to move intermittently by the Geneva indexing mechanism to complete a series of functions, such as automatic pipe arrangement, automatic pipe laying, automatic filling, internal and external heating, tail sealing, code pressing, edge cutting, finished product exit, etc;
4. Accurate filling measurement, stable and adjustable heating time, beautiful, neat, firm and sanitary appearance of sealing tail;
5. The whole machine runs stably and reliably without noise and other pollution;
About us:
The first of China;The leading of world;The best of national brand
FAQ:

Q1. Can we customize it??

A: Yes, We can customize according to your requirements and production capacity. Flexible production line.

Q2. What about the lead time?

A:Some machines are shipped within 7 days, and samples can be sent for free testing.

Q3: What kind of payments do you accept?

A:T/T, L/C, Western Union, etc..

Q4: Do you offer guarantee for the products?

A: Yes, we offer 1 year warranty to our products,All accessories damaged within one year (except for human damage) will be borne by our company, including freight.

Q5: What's the MOQ?

A:MOQ is 1 set.
