ISO9001 Fully Automatic Servo Oral Liquid Filling Machine For Daily Chemical Products
ISO9001 Fully Automatic Servo Oral Liquid Filling Machine For Daily Chemical Products
ISO9001 Fully Automatic Servo Oral Liquid Filling Machine For Daily Chemical Products
ISO9001 Fully Automatic Servo Oral Liquid Filling Machine For Daily Chemical Products
ISO9001 Fully Automatic Servo Oral Liquid Filling Machine For Daily Chemical Products
ISO9001 Fully Automatic Servo Oral Liquid Filling Machine For Daily Chemical Products
ISO9001 Fully Automatic Servo Oral Liquid Filling Machine For Daily Chemical Products
ISO9001 Fully Automatic Servo Oral Liquid Filling Machine For Daily Chemical Products
ISO9001 Fully Automatic Servo Oral Liquid Filling Machine For Daily Chemical Products
ISO9001 Fully Automatic Servo Oral Liquid Filling Machine For Daily Chemical Products
ISO9001 Fully Automatic Servo Oral Liquid Filling Machine For Daily Chemical Products
ISO9001 Fully Automatic Servo Oral Liquid Filling Machine For Daily Chemical Products
Specifications
Brand Name :
Oral Liquid Filling Machine For Daily Chemical Products
Certification :
CE ISO9001
Place of Origin :
Jiangsu, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5 sets per month
Delivery Time :
10-15 days
Packaging Details :
Our products are packed in boxs.We will check that if the machine can run before it is sent out.When you receive the goods,please open the package to check out if the goods are in good condition before the courier.If the boxs are damaged or other situation
Application :
Oral Liquid Filling Machine For Daily Chemical Products
Type :
packing machine
Advantage :
Efficiency
Filling speed :
75BPM
Operation :
Automatic Operation
Description

Oral Liquid Filling Machine For Daily Chemical Products

The filling components are easy to disassemble. The hopper valve body, piston, injection head, etc. can be quickly disassembled without any tools and are easy to clean, disinfect and sterilize.

The rotary valve installed in this machine adopts an integral design, which is easy to disassemble and clean.

The upper tube performs pre-pressure function at the same time to solve the customer's problem of unstable upper tube due to differences in packaging materials.

1 Applicable materials Plastic pipe, aluminum-plastic composite pipe
2 Filling range

2ml-400ml

*The filling capacity range varies depending on the physical properties of the raw materials and the feeding device.
3 Production speed

60pie/min(Take 50ml product as an example)

*Actual production capacity varies depending on product size, packaging material, material characteristics, etc.
4 Filling accuracy

≤±0.5%

*Measuring accuracy varies depending on material characteristics, filling volume and feeding device.
5 Applicable pipe diameter Φ13-Φ50mm
6 Applicable pipe length 70(No cover included)-230mm(Covered)
7 Material box volume 45L
8 Applicable material viscosity 60000CPS(Based on standard plunger pump)
9 power supply AC 380V
10 monitor rate 4.5KW
11 working pressure

0.6 ~0.8Mpa

(Dry, clean compressed air must be used)
12 Air consumption 50L/Min
13 weight 700Kg
14 Dimensions 1920*1083*2100mm(L*W*H)

Features

1. tube filling and sealing machine is mainly used for primary transmission principle;
2. Using imported sensors and other electrical components control, a change of the old model of pneumatic control components, not easy to abrasion;

3. The rotary table equipped with fixture is driven to move intermittently by the Geneva indexing mechanism to complete a series of functions, such as automatic pipe arrangement, automatic pipe laying, automatic filling, internal and external heating, tail sealing, code pressing, edge cutting, finished product exit, etc;
4. Accurate filling measurement, stable and adjustable heating time, beautiful, neat, firm and sanitary appearance of sealing tail;
5. The whole machine runs stably and reliably without noise and other pollution;
The vacuum liquid filling machine can prevent the fragrance of liquid from spreading,this is especially good for perfume filling.It is full automatic and can work with automatic capping machine to realize automated production.Multiple filling nozzles can be customized according to production needs.
About us:
The first of China;The leading of world;The best of national brand
FAQ:

Q1. Can we customize it??

A: Yes, We can customize according to your requirements and production capacity. Flexible production line.

Q2. What about the lead time?

A:Some machines are shipped within 7 days, and samples can be sent for free testing.

Q3: What kind of payments do you accept?

A:T/T, L/C, Western Union, etc..

Q4: Do you offer guarantee for the products?

A: Yes, we offer 1 year warranty to our products,All accessories damaged within one year (except for human damage) will be borne by our company, including freight.

Q5: What's the MOQ?

A:MOQ is 1 set.

Contact:Cyn.wu

Wechat/Whatsapp:0086-13921010106
