Fully Automatic Customized More function filling machine 20-300ml different materials in stock
Fully Automatic Customized More function filling machine 20-300ml different materials in stock
Fully Automatic Customized More function filling machine 20-300ml different materials in stock
Fully Automatic Customized More function filling machine 20-300ml different materials in stock
Fully Automatic Customized More function filling machine 20-300ml different materials in stock
Fully Automatic Customized More function filling machine 20-300ml different materials in stock
Fully Automatic Customized More function filling machine 20-300ml different materials in stock
Fully Automatic Customized More function filling machine 20-300ml different materials in stock
Specifications
Brand Name :
Terry
Certification :
CE ISO9001
Place of Origin :
Jiangsu, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5 sets per month
Delivery Time :
10-15 days
Packaging Details :
Our products are packed in boxs.We will check that if the machine can run before it is sent out.When you receive the goods,please open the package to check out if the goods are in good condition before the courier.If the boxs are damaged or other situation
Filling speed :
35-40 BPM ( in 10ml)
Air Consumption :
0.6m³/min
Controll System :
Plc
Filling Accuracy :
±1%
Filling Nozzles :
2 Nozzles
Description

GX-2-2S water emulsion turntable all-in-one machine is composed of blowing and suction, filling, internal plug pressing, capping, clamping and other parts. The equipment adopts the working modes of manual bottle placing, automatic blowing and suction, automatic filling, manual inner stopper placing, automatic inner stopper pressing, manual cap placing, automatic outer cap rotating and automatic clamping. The equipment covers a small area and is equipped with an adjustable bottle mold suitable for products with multiple specifications.

2 sets of negative ion generator and electrostatic and dust removal system imported from Japan.

Adopt servo motor for filling, with high filling accuracy; The filling speed can be adjusted to achieve different filling speeds for different materials, effectively solving the problem of material foaming.

Application 4 in 1 more function filling machine
Filling range
 2-50ml (* The filling capacity range varies according to the material properties of the raw material and the feeding device.)
Filling method

Squeeze pump filling
production rate

35-40 bottles / min (as shown in 10ml) (* The actual capacity, according to the size of the product packaging material material characteristics and change (Sililone tube fatigue, 8-10 hours calibration flow)
Filling accuracy 2-10ml±0.1g；11-15ml±0.2g；16-50ml±0.3g； (* The measurement accuracy varies according to the material characteristics, filling capacity and feeding device)
Available range of bottle mold Φ10-70mm * (Within 10-25mm diameter can be used to meet the production demand)
Applicable cover diameter Φ20-55mm (The distance between the pump nozzle to the center of the lid should be less than 45mm)
Main body shape size

2000*2000*1800mm(L*W*H)
weight

About 1,500 Kg

Features

1. xxx type hose filling and sealing machine is mainly used for primary transmission principle;
2. Using imported sensors and other electrical components control, a change of the old model of pneumatic control components, not easy to abrasion;

3. The rotary table equipped with fixture is driven to move intermittently by the Geneva indexing mechanism to complete a series of functions, such as automatic pipe arrangement, automatic pipe laying, automatic filling, internal and external heating, tail sealing, code pressing, edge cutting, finished product exit, etc;
4. Accurate filling measurement, stable and adjustable heating time, beautiful, neat, firm and sanitary appearance of sealing tail;
5. The whole machine runs stably and reliably without noise and other pollution;
The vacuum liquid filling machine can prevent the fragrance of liquid from spreading,this is especially good for perfume filling.It is full automatic and can work with automatic capping machine to realize automated production.Multiple filling nozzles can be customized according to production needs.
Packing:

Fully Automatic Customized More function filling machine 20-300ml different materials in stock

About us:
The first of China;The leading of world;The best of national brand

FAQ:

Q1. Can we customize it??

A: Yes, We can customize according to your requirements and production capacity. Flexible production line.

Q2. What about the lead time?

A:Some machines are shipped within 7 days, and samples can be sent for free testing.

Q3: What kind of payments do you accept?

A:T/T, L/C, Western Union, etc..

Q4: Do you offer guarantee for the products?

A: Yes, we offer 1 year warranty to our products,All accessories damaged within one year (except for human damage) will be borne by our company, including freight.

Q5: What's the MOQ?

A:MOQ is 1 set.
